15kV medium voltage cable
Zhengzhou Jinhang High-tech CO.,LTD
See what’s includedHide breakdown
- FOB goods (500)
- $37,675
- Ocean freight + handling (1.5 CBM)
- $880
- US duty (2.7%)
- $1,017
- Section 301 tariff (25.0%)
- $9,419
- Customs fees (MPF/HMF)
- $178
Estimate in USD to a US port using category averages (HTS 8536/8504/8507), rates as of 2026-09. Other countries on request. A quote from your agent uses real carton sizes, freight and the exact tariff line.
- FOB goods (500)
- $37,675
- Ocean freight + handling (1.5 CBM)
- $880
- US duty (2.7%)
- $1,017
- Section 301 tariff (25.0%)
- $9,419
- Customs fees (MPF/HMF)
- $178
Estimate in USD to a US port using category averages (HTS 8536/8504/8507), rates as of 2026-09. Other countries on request. A quote from your agent uses real carton sizes, freight and the exact tariff line.
Verify from $29 · written report in 3 business days · 100% refund if not satisfied
15kV medium voltage cable
Zhengzhou Jinhang High-tech CO.,LTDSee what’s includedHide breakdown
- FOB goods (500)
- $37,675
- Ocean freight + handling (1.5 CBM)
- $880
- US duty (2.7%)
- $1,017
- Section 301 tariff (25.0%)
- $9,419
- Customs fees (MPF/HMF)
- $178
Estimate in USD to a US port using category averages (HTS 8536/8504/8507), rates as of 2026-09. Other countries on request. A quote from your agent uses real carton sizes, freight and the exact tariff line.
- FOB goods (500)
- $37,675
- Ocean freight + handling (1.5 CBM)
- $880
- US duty (2.7%)
- $1,017
- Section 301 tariff (25.0%)
- $9,419
- Customs fees (MPF/HMF)
- $178
Estimate in USD to a US port using category averages (HTS 8536/8504/8507), rates as of 2026-09. Other countries on request. A quote from your agent uses real carton sizes, freight and the exact tariff line.
Verify from $29 · written report in 3 business days · 100% refund if not satisfied
About this product
- Materials: aluminum or copper
- Size: 35-1000mm2
- Color: black, red, gray, etc.
- Exports to: Mainland China, Africa, Middle East, Southeast Asia, South Asia, USA and Canada, Latin America, EU, Other European Countries, Others
- Made in: Henan, China
About this product
- Materials: aluminum or copper
- Size: 35-1000mm2
- Color: black, red, gray, etc.
- Exports to: Mainland China, Africa, Middle East, Southeast Asia, South Asia, USA and Canada, Latin America, EU, Other European Countries, Others
- Made in: Henan, China
Product details
| Materials | aluminum or copper |
|---|---|
| Size | 35-1000mm2 |
| Color | black, red, gray, etc. |
Product details
| Materials | aluminum or copper |
|---|---|
| Size | 35-1000mm2 |
| Color | black, red, gray, etc. |
From the supplier
Aluminum or copper conductor 15kV cable XLPE insulation with concentric wire neutral
Applications
For use on single phase and three phase primary underground distribution systems operating at 15 kV phase to phase at 100 % and 133 % insulation level. Suitable for either direct burial or installation in ducts.
Construction
aluminum or copper concentrically stranded compressed conductor, triple single head extruded conductor shield, XLPE (cross-linked polyethylene) insulation and easy strippable insulation shield, all dry nitrogen cured; solid bare aluminum or copper wires uniformly spaced around the cable as a concentric neutral; LLDPE jacket with extruded longitudinal colored stripes, surface printed.
Standards
AEIC CS8 Specification for Extruded Dielectric Shielded Power Cables Rated 5 through 46 kV
ICEA S-94-649 Standard for Concentric Neutral Cables Rated 5,000 - 46,000 V
ICEA T-31-610 Guide for Conducting a Longitudinal Water Penetration Resistance Tests on Blocked Conductors
ICEA T-34-664 Test Method for Conducting Longitudinal Water Penetration Resistance Tests on Longitudinal Water Blocked Cables
UL-1072 MV90
Options
XLPE insulation
Filled strand
Cable core water blocking
Notes
Ampacities are based on the NEC.
Cable Tray: Three single cables, installed in uncovered cable tray in accordance with NEC Section 392.13; operating at 90 ºC conductor, at an ambient temperature of 40 ºC.
Buried Duct: Three cables per duct operating at 90 ºC conductor, 20 ºC ground ambient, earth ρ = 90, 100 % load factor.
Conduit in Air: Three cables per isolated conduit in air at 40 ºC; operating at 90 ºC conductor (NEC Table 310.73).
Maximum conductor temperature: 90 ºC normal continuous, 130 ºC overload, 250 ºC short circuit.
From the supplier
Aluminum or copper conductor 15kV cable XLPE insulation with concentric wire neutral
Applications
For use on single phase and three phase primary underground distribution systems operating at 15 kV phase to phase at 100 % and 133 % insulation level. Suitable for either direct burial or installation in ducts.
Construction
aluminum or copper concentrically stranded compressed conductor, triple single head extruded conductor shield, XLPE (cross-linked polyethylene) insulation and easy strippable insulation shield, all dry nitrogen cured; solid bare aluminum or copper wires uniformly spaced around the cable as a concentric neutral; LLDPE jacket with extruded longitudinal colored stripes, surface printed.
Standards
AEIC CS8 Specification for Extruded Dielectric Shielded Power Cables Rated 5 through 46 kV
ICEA S-94-649 Standard for Concentric Neutral Cables Rated 5,000 - 46,000 V
ICEA T-31-610 Guide for Conducting a Longitudinal Water Penetration Resistance Tests on Blocked Conductors
ICEA T-34-664 Test Method for Conducting Longitudinal Water Penetration Resistance Tests on Longitudinal Water Blocked Cables
UL-1072 MV90
Options
XLPE insulation
Filled strand
Cable core water blocking
Notes
Ampacities are based on the NEC.
Cable Tray: Three single cables, installed in uncovered cable tray in accordance with NEC Section 392.13; operating at 90 ºC conductor, at an ambient temperature of 40 ºC.
Buried Duct: Three cables per duct operating at 90 ºC conductor, 20 ºC ground ambient, earth ρ = 90, 100 % load factor.
Conduit in Air: Three cables per isolated conduit in air at 40 ºC; operating at 90 ºC conductor (NEC Table 310.73).
Maximum conductor temperature: 90 ºC normal continuous, 130 ºC overload, 250 ºC short circuit.
