Jinan Acme CNC Equipment Co., Ltd.

CONTENT

I      WHO WE ARE

II    CONFIGURATION

III   ADVANTAGES

IV  MAIN PARTS

V    MODERN FACTORY

VI  CE AND PATENTS

1. WHO WE ARE
2.


Corporate Vision: We are committed to becoming the leader in laser tube processing industry!

Corporate mission: We focus on high power sheet laser and laser tube cutting machine R&D and production, providing customers around the world with intelligent laser tube processing solutions.

Corporate values: Based on customer needs, we stick on continuous innovation, to share a win-win situation with both our customers and employees!

Located in Cui Zhai Town, Jinan City, Shandong Province, Jinan Acme CNC Equipment Co., Ltd. is mainly engaged in R & D, manufacturing and sales of laser cutting machines, providing comprehensive laser equipment solutions to customers all over the world.

Our team has many years of experience in the field of laser equipment, with industry-leading technology and continuous R&D capabilities. As a customer-oriented enterprise, we provide customers with the most cost-effective laser equipment products.

The United States Haas, Japan Mazak and Taiwan Ying-yuan and other high-precision CNC machining centers, together with Italy COLGAR large gantry milling machine are deployed in the manufacturing of our laser equipment, all the core components of the machines are independently designed and manufactured with high-precision.

Fiber laser tube cutting machine is the our core product and we have successfully developed semi-automatic laser tube cutting machine, automatic laser tube cutting machine, tube-plate machine and high-power flat sheet cutting machine and other products. Product quality and customer service get the unanimous approval from the market. Self-developed tube laser cutting machine with automatic loading system has gained a number of national patents, and all our products are in line with CE and FDA certification.

Our laser cutting machines are widely used in sports equipment, automobile manufacturing, metal art furniture, medical equipment, building decoration, machinery manufacturing, electrical equipment and elevator equipment and many other fields.

1. CONFIGURATION

NO.

NAME

QTY

BRAND

• 1

LASER SOURCE

1

IPG/RAYCUS

• 2

LASER HEAD

1

PRECITEC

• 3

SYSTEM

1

CYPCUT

• 4

BED

1

ACME LASER

• 5

ELECTRICAL

1

SCHNEIDER

• 6

PNEUMATICAL

1

AIRTAC

• 7

RAIL

1

PMI

• 8

RACK

1

YYC

• 9

SERVO MOTOR

4

YASKAWA

• 10

REDUCER

4

MOTOVARIO

• 11

WATER CHILLER

1

HANLI

• 12

DUST EXTRACTION

1

ACME LASER

• 13

WASTE COLLECTION

4

ACME LASER

• 14

EXCHANGE TABLE

2

ACME LASER

1. ADVANTAGES
   1. BED
   2. Stable earthquake resistance, good rigidity and high precision.
   3. The bed is made of 16-25MM steel plate, which is cut and welded in the whole plate. G.W. is more than 20T. After welding, the whole bed is placed in the furnace and heated to 600 degrees. Then it is kept to 200 degrees and then removed from the furnace for natural cooling. After the heat aging, the whole bed will be placed on the COLGAR large milling machine for planning and milling, and the whole process will last for 15-20 days.
   4. The rear bed is welded with a large square tube of 10mm thick and weighs 2t. The bed is specially designed to prevent it from being burnt down by high-power lasers.
   5. The bed is independently developed with overall design. The whole processing of the bed is with imported processing center, which ensures that the guide surface and the rack surface are processed at one time to ensure accuracy.
   6. Long service life, no deformation for decades.

1. CUTTING TABLE
2. A pointed, dense workbench, each capable of carrying up to 2t of weight.

Double platform automatic exchange design, loading while processing, greatly

improving work efficiency.

    Refined iron chain drives double platform exchange, which is sturdy and durable, long service life and not easy to wear and break.

    Gantry structure, top-grade high-precision high-speed rack and pinion, bilateral drive transmission and linear guide rail, stable transmission and high precision.

    The beam is welded with aluminum alloy, which is light in weight, strong in strength and non-deformable.

3    WASTE COLLECTION

    Waste collection trays at the bottom of the bed to collect waste from the production process and collect small parts at any time.

4    RAIL

    Taiwan PMI linear guide, precision wear-resistant

    Selected special metal materials, high wear resistance and rigidity

    Smooth rolling, low friction coefficient, minimizing wear

5    TRANSMISSION

    Taiwan YYC rack, 2M helical gear, grinding 6 grades to ensure high-precision motion under a variety of complex conditions.

    Adopt the most advanced grinding and tooth making process, high precision in mass production

IV    MAIN PARTS

     IPG /RAYCUS LASER SOURCE

    MOTOVARIO REDUCER

      YASKAWA SERVO MOTORS

     FLEXIBLE CONTROL PANEL WITH REMOTE CONTROLLER（NO COVER）

     Germany Precitec automatic focusing laser head enables automatic focusing, perfect cutting of workpieces for automatic zooming and perforation acceleration of steel plates of different thicknesses

     HANLI WATER CHILLER

     WHOLE STEEL PANEL CUT AND WELDED

     The bed is integrally planed and milled by the Italian GOLCAR machine center to ensure high-precision smooth movement of the guide rails.

     Heavy-duty material with thick blade shaped work platform

Exchange platform chain transmission, the chain has a special motion protection groove, smooth running, not easy to break, prevent wear

      The wiring of the line is clear, and it is convenient to check or replace parts.

     PMI RAIL

     YYC RACK

     FREE consumables(5 PCS)

Protective glass

Nozzle

Ceramic Holder

V    MODERN FACTORY

VI    CE AND PATENTS
