About this product
- Materials: steel
- Size: Based on model/Equipment model
- Color: According to customer requirements
- Exports to: Mainland China, Africa, Middle East, Southeast Asia, South Asia, Central Asia, USA and Canada, Latin America, Russia, EU, Other European Countries, Japan and South Korea, Hong Kong China, Macao China and Taiwan China, Others
- Made in: Shanghai, China
About this product
- Materials: steel
- Size: Based on model/Equipment model
- Color: According to customer requirements
- Exports to: Mainland China, Africa, Middle East, Southeast Asia, South Asia, Central Asia, USA and Canada, Latin America, Russia, EU, Other European Countries, Japan and South Korea, Hong Kong China, Macao China and Taiwan China, Others
- Made in: Shanghai, China
Product details
| Materials | steel |
|---|---|
| Size | Based on model/Equipment model |
| Color | According to customer requirements |
Product details
| Materials | steel |
|---|---|
| Size | Based on model/Equipment model |
| Color | According to customer requirements |
From the supplier
Vibrating screen
[Input Size]
[Production Capacity] 12-650T/h
[Processed Materials] Pebble, granite, basalt, limestone, iron ore, copper ore, tuff and so on
[Applications] Mining, building materials, transportation, energy, chemical industry, etc
The series of product is vibrated by the circling motion, and the amplitude strength can be adjusted. The screening line of material is long. It provides the multi-screening, various models of screening cleaning, high screening efficiency, and suitable screening task of mining and sandstones industry.
Working principle:
It adjusts the amplitude by tube-shaped violent vibration screen of eccentric shaft and eccentric blocks. The body moves like a circle, in order to make the materials screened.
Vibrating screen, also known as round vibrating screen, when it is working, vibrating screen will up and down in the role of the exciter shaking, the material falls on the first layer of the sieve, will be separated vibration, small particles of material fall from the screen aperture. The vibrating screen principle is very simple, the design is more convenient for manufacturing
Features:
It features of long flowing line, many screening specifications, strong violent vibration force, high screening efficiency, small vibrating noises, firm and durable construction, convenient maintenance and safe operation.
Technical parameters:
ModelModel3YK12303YK12373YK15483YK18483YK18603YK21603YK24603YK3070Screen Size
Sieving specifications
(mm)1200×30001200×37001500×48001800×48001800×60002100×60002400×60003000×7000number of layers
Layer
(Layer)33333333Aperture Size
Screen hole size
(mm)3-506-505-805-805-805-505-1505-150Feed Particle Size
Feeding size
(mm)≤200≤200≤400≤400≤400≤400≤400≤400Processing Capacity
Capacity
t/h)12～8015～12050～20050～25080～320100～380150～430150～650Motor power
Motor power
(kw)5.5111518.522303045Vibration Frequency
Vibration frequency
(r/min)800-970845910970970730730730Double Amplitude
Two amplitudes
(mm)87.5888888Inclination Angle
Inclination of sieve surface
(℃)2020152020202020Long
Length
(mm)31223557524350005994623064207500Width
Wode
(mm)20502483304236263462371541505060Height
High
(mm)27002813342032503880433042104010
