About this product
- Materials: GALVANIZED STEEL
- Size: 16000X1000X1200
- Color: white
- Exports to: Mainland China, Africa, Middle East, Southeast Asia, South Asia, Central Asia, Russia, EU, Other European Countries, Japan and South Korea, Others
- Made in: Jiangsu, China
About this product
- Materials: GALVANIZED STEEL
- Size: 16000X1000X1200
- Color: white
- Exports to: Mainland China, Africa, Middle East, Southeast Asia, South Asia, Central Asia, Russia, EU, Other European Countries, Japan and South Korea, Others
- Made in: Jiangsu, China
Product details
| Materials | GALVANIZED STEEL |
|---|---|
| Size | 16000X1000X1200 |
| Color | white |
Product details
| Materials | GALVANIZED STEEL |
|---|---|
| Size | 16000X1000X1200 |
| Color | white |
From the supplier
TECHNICAL DETAILS
Un-coiler
1. Capacity: 2 tons
2. Material: #45 steel quenched
3. Inner diameter: 410~ 580mm
Main roll former
1. Stations: 12
2. Rollers material: CR 15;HRC 60. chrome coated: 0.03~0.05mm. the Strength in Mpa :70 TON,800 MPA
3. Shaft material: Diameter: 40mm, material is #45 steel. Quenched: hot treatment. The strength of the Main Shaft in Mpa:70 tons, 650MPA
4. Bearing brand: FAG Germany
5. Main Motor: 5.5 KW, 380V, 50HZ
CHAMICAL COMPOSITION:
C
SI
MN
P
S
CR
NI
CU
MO
AI
V
B
Shaft
0.450
0.220
0.540
0.027
0.008
0.050
0.020
0.010
0.000
0.009
0.000
0
Rollers
1.00
0.32
0.33
0.011
0.003
1.49
0.05
0.00
0.02
0.041
Cutter
1.57
0.34
0.38
0.022
0.010
11.10
0.18
0.14
0.48
Cut knife
2.04
0.23
0.23
0.020
0.010
11.66
0.12
0.06
PLC Control Cabinet:
1. Touch screen brand: Delta
2. PLC brand: Delta
3. Inverter brand: Delta
4. Main components for low pressure electricity: Schneider Germany
Output table
1. Length: 6 meters
2. Drive type: Rollers
CUTTING PLATFORM
1. Cutting type: Hydraulic Fly cutter with servo control system
2. Motor: 4KW; 380V; 50HZ
3. Material of cut die: CR12MOV; Quenched; the Strength in MPA: 950
