Application

KSD03 thermal protector is a kind of over temperature and over current protection device.Advantages of large contact capacity,snap action and high load .It is widely used in heat         seater and electric blanket etc.

KSD03 Overheat and Overcurrent Protector. High Contact Capacity, Fast Trip Action, Handles High Load, Mainly Used in Car Seat Heaters, Electric Blankets, etc.

2 Structure

KSD03 thermal protector uses bimetal disc of geometric forms to make bimetal snap action according to heat surface and current heat effect,then make the action of movable contact to cut off or connect circuit, which plays a over temperature and over load protection role.Advantages of high sensitivity.the thermal protector case is filling with epoxy resin to  insulation,wear-resisting, moisture-proof and preventing leakage .

Thermal protector uses bimetal discs of certain geometric shapes, no auxiliary mechanism needed. Relies only on the bimetal disc's own temperature sensing and current heat effect, causing the bimetal element to change rapidly, directly driving the contact to automatically cut off or switch on the circuit, providing overheat and overload protection. Has advantages such as high sensitivity. Thermal protector's shell is sealed with epoxy resin material, with characteristics such as insulation, wear-resistance, moisture-resistance, and leak prevention.

3  Model and structure

Product Classification, Model And Structure

3.1 Type

Product Category and Model

   KSD03    XXX℃

3.2 Structure

Appearance and Structure

Contact Capacity: DC28V8A, DC16V10A
