Principle and structure

15AM-D series thermal protector is a current sensitive and temperature automatic response device. It is connected in series to the winding of motor. The protector changes with the temperature of winding and current of a motor. When the heat generated by the increasing temperature and current from the protected appliances transmits to double-metal element, and reaching the temperature value of scheduled movement, the double-metal element will move immediately so that the contact will be switched off and the circuit will be cut off. When the temperature of motor winding decreases to the rated temperature value of reposition, bimetal element will return to its initial state, the moving contact will be closed the circuit will be on.

Instructions and applications

15AM-D series thermal protector has advantages of trip current sensitively and control temperature precisely. It is applied various Induction Motor，Universal Motor, transformers, rectifiers, electric tools,automobile motor, electro-thermal appliances and etc.
