Slant bed CNC lathe machine
- FOB goods (100)
- $1,995,000
- Ocean freight + handling (1.0 CBM)
- $820
- US duty (3.5%)
- $69,825
- Section 301 tariff (25.0%)
- $498,750
- Customs fees (MPF/HMF)
- $3,128
Estimate in USD to a US port using category averages, rates as of 2026-09. Other countries on request. A quote from our desk uses real carton sizes, freight and the exact tariff line.
- Service
- From $29 per supplier (Verify)
- You get
- Phone and video verification, a quote sheet and a written report
- Turnaround
- 3 business days
- Contact details
- Sent to you once your request is confirmed
If we can't reach the supplier within 3 business days, we refund the fee.
Slant bed CNC lathe machine
- FOB goods (100)
- $1,995,000
- Ocean freight + handling (1.0 CBM)
- $820
- US duty (3.5%)
- $69,825
- Section 301 tariff (25.0%)
- $498,750
- Customs fees (MPF/HMF)
- $3,128
Estimate in USD to a US port using category averages, rates as of 2026-09. Other countries on request. A quote from our desk uses real carton sizes, freight and the exact tariff line.
- Service
- From $29 per supplier (Verify)
- You get
- Phone and video verification, a quote sheet and a written report
- Turnaround
- 3 business days
- Contact details
- Sent to you once your request is confirmed
If we can't reach the supplier within 3 business days, we refund the fee.
About this product
- Materials: cast iron
- Size: 2830x1750x2150mm
- Color: brown+white+black
- Exports to: Mainland China, Africa, Middle East, Southeast Asia, South Asia, Central Asia, USA and Canada, Latin America, Russia, EU, Other European Countries, Japan and South Korea, Hong Kong China, Macao China and Taiwan China, Others
- Made in: Anhui, China
About this product
- Materials: cast iron
- Size: 2830x1750x2150mm
- Color: brown+white+black
- Exports to: Mainland China, Africa, Middle East, Southeast Asia, South Asia, Central Asia, USA and Canada, Latin America, Russia, EU, Other European Countries, Japan and South Korea, Hong Kong China, Macao China and Taiwan China, Others
- Made in: Anhui, China
Product details
| Materials | cast iron |
|---|---|
| Size | 2830x1750x2150mm |
| Color | brown+white+black |
From the supplier
The CNC lathe machine is high rigid 45 degree slant bed
X/Z Taiwan linear guidewway
X/Z Taiwan high precision ballscrew
A2-5 spindle unit
Artistic appearance with high precision
CNC system can be FANUC, SIEMENS and GSK
Specification CK36L Max.swing over bed Π€360mm Max.swing over carriage Π€210mm Max. cutting length 500/750mm Rail width 284mm Spindle nose A2-5 (optional:A2-6) Spindle bore Π€56mm (65mm) spindle hole after hydr Π€50mm Taper of spindle bore 1:20 Chuck size 6" (optional:8") Range of spindle speed 150-4200rpm X-axis travel 210mm Z-axis travel 500/750mm X/Z rapid speed 20/20m/min Electronic turret 8 Max.section of tool 20x20mm Stroke of tailstock sleeve 80mm Diameter/Hole of tailstock sleeve Π€60mm/MT4 Main motor power 5.5kw (optiona:7.5kw) Coolant pump power 370w Overall dimensions L x W x H 2630/2910x1550x1750mm Packing size L x W x H 2830/3130x1750x2150mm Net weight 2700/3000kg Gross weight 3100/3400kg
About the supplier
Main products: Lathe,Miller,Press brake,Grinding machine,CNC Machining center,Drilling machine,Planing Machine/Slotting Machine,Drilling and Milling Machine,Milling Lathe
- βExhibited at 10 of the last 10 Canton Fairs
- βForeign Trade Company
- βFounded 2014
- β1 certificate on file
- Exhibited at 10 of the last 10 Canton Fairs
- Foreign Trade Company
- Founded 2014
- 1 certificate on file
