SKYMASTER Traditional machine tool equipment for machining centers
The supplier hasn’t listed a price. We can get their current prices and MOQ.
- Service
- From $29 per supplier (Verify)
- You get
- Phone and video verification, a quote sheet and a written report
- Turnaround
- 3 business days
- Contact details
- Sent to you once your request is confirmed
If we can't reach the supplier within 3 business days, we refund the fee.
SKYMASTER Traditional machine tool equipment for machining centers
The supplier hasn’t listed a price. We can get their current prices and MOQ.
- Service
- From $29 per supplier (Verify)
- You get
- Phone and video verification, a quote sheet and a written report
- Turnaround
- 3 business days
- Contact details
- Sent to you once your request is confirmed
If we can't reach the supplier within 3 business days, we refund the fee.
About this product
- Materials: See figure
- Size: See Image
- Color: See figure
- Exports to: Mainland China, Africa, Middle East, Southeast Asia, South Asia, Central Asia, USA and Canada, Latin America, Russia, EU, Other European Countries, Japan and South Korea, Hong Kong China, Macao China and Taiwan China, Others
About this product
- Materials: See figure
- Size: See Image
- Color: See figure
- Exports to: Mainland China, Africa, Middle East, Southeast Asia, South Asia, Central Asia, USA and Canada, Latin America, Russia, EU, Other European Countries, Japan and South Korea, Hong Kong China, Macao China and Taiwan China, Others
Product details
| Materials | See figure |
|---|---|
| Size | See Image |
| Color | See figure |
From the supplier
Project Name
Unit
VU400 Parameters
Control System
FANUC 0i-MF Plus
(5-Axis 4-Linked)
Stroke
X-Axis Stroke (Work Table)
mm
600
Y-Axis Stroke (Saddle)
mm
580
Z-Axis Stroke (Spindle Head)
mm
530
Spindle Nose to Worktable Distance
mm
100～630
Distance from Spindle Center to Column Guard
mm
630
Work Table
Work Table Diameter
mm
Φ400
T-Slot (Qty × Width)
mm
8X12
Worktable Maximum Load Capacity
kg
Horizontal 300/Inclined 250
Rotation Angle
A-axis
+90º～-120 º
C-axis
360º
Maximum RPM
A-axis
rpm
22.2
C-axis
rpm
33.3
Spindle
Spindle Bore Taper
BT40 (45-degree Pull Pin)
Maximum Spindle Speed
rpm
10000
Spindle Motor Specification (Continuous/Max)
kW
11/20.4
Spindle Torque (Continuous/Maximum)
N.m
52.5/130
Control Axis
Three-Axis Rapid Feed Speed (X-Axis, Y-Axis)
mm/min
36000
Three-axis Fast Feed Speed (Z-axis)
mm/min
24000
Three-Axis Feed Speed (X-Axis, Y-Axis, Z-Axis)
mm/min
1-10000
tool magazine
Tool Changer Form
Knife Arm Type
Tool Changer Capacity
Batch
24
Maximum Tool Diameter
mm
φ80/φ130
Maximum Tool Length
mm
300
Maximum Tool Weight
kg
8
Full-Range Positioning Accuracy (VDI/DGQ3441)
mm
P0.008
Repeat Positioning Accuracy (VDI/DGQ3441)
mm
Ps0.006
Air Pressure
MPa
0.6～0.8
Pump Flow
L/min
66
Power Supply
3/PE,AC380V,50Hz
Electrical Capacity
kVA
30
Floor Area (Length × Width × Height)
mm
4200×3510×3170
Weight
kg
8250
