Technical Data Sheet

S120 FanChu Semi-Synthetic Coolant Package-High oil Content package

Description

S120 FanChu Semi-Synthetic Coolant Package-High oil Content package is a semi-synthetic cutting fluid compound agent specially developed for metal processing. This product must be used with component B. By adding base oil with different proportions of each component, a semi-synthetic Microemulsion Cutting Fluid with high cost performance ratio can be prepared. The semi-finished compound package does not contain harmful substances such as heavy metals, sodium nitrite and phenols. The prepared product has good stability and long service life.

Features and benefits

• The finished product has excellent cooling, cleaning and rust prevention functions.

• Microemulsion has good stability and long service life.

• Excellent lubrication performance, can prolong the service life of the tool and improve the surface quality of the workpiece.

• Using non-standard oil as base oil can greatly reduce the comprehensive cost.

Typical physical and chemical properties

S120 FanChu Semi-Synthetic Coolant Package-High oil Content package

Unit

Technical indicators

A component

Physical state

/

Transparent liquid

Color

/

light yellow

PH5%

/

9.05

Density @ 20℃

㎏/m 3

1.15±0.05

Test item

Test method

Technical index

Appearance

Concentrated liquid

visual inspection

transparency liquid

Appearance

5% wt. Diluent

visual inspection

Homogeneous emulsion

ph value

5%wt

ph meter

9.05

Finished product

Rust resistance, (cast iron, 35°C±2°C, RH>95%;

GB/T6144

Level A

Single piece 24h, lamination 8h)

Corrosivity of aluminium,

steel disc

GB/T6144

Level A

(55 ~C+2 ~C; 8h)

Red copper

Level A

LY12 aluminum

Level A

Application

It can be used for the processing of cast iron, alloy steel, carbon steel, zinc alloy, aluminium, aluminium alloy and other materials.

Usage method

1, Distribution: At room temperature, the two components of the composite package are proportionally added to the container, then the base oil is added, and the semi-synthetic concentrate is obtained after mixing with clear and transparent.

2, Use ratio: component A 22-30%; component B 22-30%; component A: component B = 1:1 is the best; base oil 40-56%. Recommended ratio: 25% of component A, 25% of component B, 50% of base oil.

3, 5-10% extreme pressure agent can be added to the system to improve the performance of the product.

4, Since the formula of the original system is diverse, it is recommended to conduct a small test before use to determine the compatibility, compatibility and stability of the product and the system.
