About this product
- Materials: Steel
- Size: 2620*692*1140
- Color: Yello, Green
- Exports to: Mainland China, Africa, Middle East, Southeast Asia, South Asia, Central Asia, USA and Canada, Latin America, Russia, EU, Other European Countries, Japan and South Korea, Hong Kong China, Macao China and Taiwan China, Others
About this product
- Materials: Steel
- Size: 2620*692*1140
- Color: Yello, Green
- Exports to: Mainland China, Africa, Middle East, Southeast Asia, South Asia, Central Asia, USA and Canada, Latin America, Russia, EU, Other European Countries, Japan and South Korea, Hong Kong China, Macao China and Taiwan China, Others
Product details
| Materials | Steel |
|---|---|
| Size | 2620*692*1140 |
| Color | Yello, Green |
Product details
| Materials | Steel |
|---|---|
| Size | 2620*692*1140 |
| Color | Yello, Green |
From the supplier
FEATURES
1.Equipped with famous brand engine, could guarantee quality stability and excellent performance.
2.Hawkeye-shaped body design, wide field of vision, and beautiful appearance
3.Imported hydraulic variable pump and fixed displacement motor, Stepless speed change, walking forward and backward.
4.Transmission uses Japanese NSK precision bearings to ensure the performance of the machine.
5.Electromagnetic clutch controls vibration for faster operation.
6.Hydraulic steering, labor-saving, flexible and convenient
7.Passed CE, SGS and ISO certification and won Red Star Award design.
ITEM NO/DETAILSSVH60SVH60CSVH60CSENGINEEngineHONDA GX390CHANGFA/CHANGCHAI186FGOLDEN FLYING FISH RD90N-1Engine typeSingle cylinder, OHV, air-cooled, four-stroke, gasolineSingle cylinder, vertical, air-cooled, four-stroke, dieselSingle cylinder, vertical, water-cooled, four-stroke, dieselNumber of cylinders1Output power (KW)9.74.85.88Rating speed(RPM)36002400Fuel consupmtion(G/KWH)313320330Lubricating oil volume(L)1.11.651.85DRIVING
Electrical equipment(V)12Drive modeVariable plunge pump, stepless speed change, two wheelWalking speed (KM/H)0--3Theoretical climbing ability(%)30STEERING
Steering modeManualEXCITING SYSTEM
Vibration wheel__Drive formMechanical transmission, electromagnetic clutchVibration frequency (HZ)65Vibration amplitude (MM)0.5Exciting force(KN)20SPRINKLING SYSTEM
Water spray formGravity-type waterCAPACITY
Hydraulic oil capacity(L)25Fuel capacity(L)6.53.510Water tank capacity (L)40SIZE
Working width(MM)692Overall length(MM)2620Machine height(MM)1140Ground clearance(MM)170Wheel track(MM)650Width of wheel(MM)650Diameter of wheel(MM)380Drum thickness(MM)10WEIGHT
Weight(KG)650Static load(N/CM)58/6356/6461.5/65.5
From the supplier
FEATURES
1.Equipped with famous brand engine, could guarantee quality stability and excellent performance.
2.Hawkeye-shaped body design, wide field of vision, and beautiful appearance
3.Imported hydraulic variable pump and fixed displacement motor, Stepless speed change, walking forward and backward.
4.Transmission uses Japanese NSK precision bearings to ensure the performance of the machine.
5.Electromagnetic clutch controls vibration for faster operation.
6.Hydraulic steering, labor-saving, flexible and convenient
7.Passed CE, SGS and ISO certification and won Red Star Award design.
ITEM NO/DETAILSSVH60SVH60CSVH60CSENGINEEngineHONDA GX390CHANGFA/CHANGCHAI186FGOLDEN FLYING FISH RD90N-1Engine typeSingle cylinder, OHV, air-cooled, four-stroke, gasolineSingle cylinder, vertical, air-cooled, four-stroke, dieselSingle cylinder, vertical, water-cooled, four-stroke, dieselNumber of cylinders1Output power (KW)9.74.85.88Rating speed(RPM)36002400Fuel consupmtion(G/KWH)313320330Lubricating oil volume(L)1.11.651.85DRIVING
Electrical equipment(V)12Drive modeVariable plunge pump, stepless speed change, two wheelWalking speed (KM/H)0--3Theoretical climbing ability(%)30STEERING
Steering modeManualEXCITING SYSTEM
Vibration wheel__Drive formMechanical transmission, electromagnetic clutchVibration frequency (HZ)65Vibration amplitude (MM)0.5Exciting force(KN)20SPRINKLING SYSTEM
Water spray formGravity-type waterCAPACITY
Hydraulic oil capacity(L)25Fuel capacity(L)6.53.510Water tank capacity (L)40SIZE
Working width(MM)692Overall length(MM)2620Machine height(MM)1140Ground clearance(MM)170Wheel track(MM)650Width of wheel(MM)650Diameter of wheel(MM)380Drum thickness(MM)10WEIGHT
Weight(KG)650Static load(N/CM)58/6356/6461.5/65.5
