About this product
- Materials: Metal
- Size: 150*120*220cm
- Color: Green
- Exports to: Mainland China, Africa, Middle East, Southeast Asia, South Asia, Central Asia, USA and Canada, Latin America, Russia, Other European Countries, Japan and South Korea, Others
- Made in: Shandong, China
About this product
- Materials: Metal
- Size: 150*120*220cm
- Color: Green
- Exports to: Mainland China, Africa, Middle East, Southeast Asia, South Asia, Central Asia, USA and Canada, Latin America, Russia, Other European Countries, Japan and South Korea, Others
- Made in: Shandong, China
Product details
| Materials | Metal |
|---|---|
| Size | 150*120*220cm |
| Color | Green |
Product details
| Materials | Metal |
|---|---|
| Size | 150*120*220cm |
| Color | Green |
From the supplier
4TN4000
Trailer hand-lifting mobile lighting tower
Trailer mobile lighting tower Series 4TN Mobile lighting equipment
Features
Equipped with imported power, quality assurance and superior performance
Equipped with metal halogen lamp, large luminous flux and long life
High-performance self-braking hand winch
Three-section lifting rod, galvanized lamp post, anti-drop, corrosion-resistant
Five windproof support legs for stable support
Integrated operating panel with rain cover
9 meters lifting height, adjustable irradiation angle, long irradiation distance
Large capacity fuel tank, long duration
Overall Size
Overall length (L)
mm
4360
Overall width (W)
mm
1430
Overall height (H)
mm
1450
Height of mast sections（HI）
mm
9
Tire and rim size(WI)
”
14
Technical Data Unit 4VA4000
Technical parameter
Unit
4TN4000
Model
4TN4000
Engine
KUBOTA
Engine Model
D1105
Engine Type
three cylinder,water-cooled,four stroke
Power
kw
12.6
Frequency
rpm
1500/1800
Combustion System
E-TVS
Engine aspiration
Naturally aspirated
Emission level
Regular
Standard configuration
SPARKS
Rating voltage（50/60HZ)
V
230/240-120
Alternator insulation
CLASS H
Alternator protection grade
IP23
Type of Lights
Regular metal halide
Luminous flux
lm
440000
Number & power of lights
w
1000*4
Number of mast sections
Section
3
Fuel tank capacity
L
110
Continuous working time
h
65
Generator starting type
Key starting
Max. against wind
m/s
20
Noise level
dB
72dB(A) at 7 meters away
Suspension & Brake
Leaf spring suspension & alone without brake
Drawbar
Adjustable lever with telescopic adjustment guide wheel
Full extending height
m
9
Wheel's rim size
“
14
Max towing speed
km/h
100
Length
mm
4360
Width
mm
Height
mm
1430
Weight
kg
960
Standard configuration
Telescopic adjustable guide wheel drawbar located under the fuselage
4pcs 1000W metal halogen lamps
Green lighting car dust cover
Galvanized lamp pole traction rod and support legs
Leaf spring suspension & alone without brake
Two 14-inch rubber tires
Equipped with self-braking hand winch
Three-section galvanized light pole
Mast sections, lamp head can rotate 360 °
Waterproof aviation plug
Integrated light control panel with rain protection cover
Tail reflector
Equipped with fire extinguisher
Optional configuration
200W LED lighting
400W metal halogen lamp
500W iodine tungsten lamp
Spherical lighting
2 lights /3 lights / 4 lights
From the supplier
4TN4000
Trailer hand-lifting mobile lighting tower
Trailer mobile lighting tower Series 4TN Mobile lighting equipment
Features
Equipped with imported power, quality assurance and superior performance
Equipped with metal halogen lamp, large luminous flux and long life
High-performance self-braking hand winch
Three-section lifting rod, galvanized lamp post, anti-drop, corrosion-resistant
Five windproof support legs for stable support
Integrated operating panel with rain cover
9 meters lifting height, adjustable irradiation angle, long irradiation distance
Large capacity fuel tank, long duration
Overall Size
Overall length (L)
mm
4360
Overall width (W)
mm
1430
Overall height (H)
mm
1450
Height of mast sections（HI）
mm
9
Tire and rim size(WI)
”
14
Technical Data Unit 4VA4000
Technical parameter
Unit
4TN4000
Model
4TN4000
Engine
KUBOTA
Engine Model
D1105
Engine Type
three cylinder,water-cooled,four stroke
Power
kw
12.6
Frequency
rpm
1500/1800
Combustion System
E-TVS
Engine aspiration
Naturally aspirated
Emission level
Regular
Standard configuration
SPARKS
Rating voltage（50/60HZ)
V
230/240-120
Alternator insulation
CLASS H
Alternator protection grade
IP23
Type of Lights
Regular metal halide
Luminous flux
lm
440000
Number & power of lights
w
1000*4
Number of mast sections
Section
3
Fuel tank capacity
L
110
Continuous working time
h
65
Generator starting type
Key starting
Max. against wind
m/s
20
Noise level
dB
72dB(A) at 7 meters away
Suspension & Brake
Leaf spring suspension & alone without brake
Drawbar
Adjustable lever with telescopic adjustment guide wheel
Full extending height
m
9
Wheel's rim size
“
14
Max towing speed
km/h
100
Length
mm
4360
Width
mm
Height
mm
1430
Weight
kg
960
Standard configuration
Telescopic adjustable guide wheel drawbar located under the fuselage
4pcs 1000W metal halogen lamps
Green lighting car dust cover
Galvanized lamp pole traction rod and support legs
Leaf spring suspension & alone without brake
Two 14-inch rubber tires
Equipped with self-braking hand winch
Three-section galvanized light pole
Mast sections, lamp head can rotate 360 °
Waterproof aviation plug
Integrated light control panel with rain protection cover
Tail reflector
Equipped with fire extinguisher
Optional configuration
200W LED lighting
400W metal halogen lamp
500W iodine tungsten lamp
Spherical lighting
2 lights /3 lights / 4 lights
