Q80sc Automatic Strapping Machine
TAIZHOU XUTIAN PACKING MACHINE CO.,LTD
The supplier hasn’t listed a price. We can get their current prices and MOQ.
Free quotes from independent agents · supplier checks approx. $5–$100 · 100% refund if not satisfied
Q80sc Automatic Strapping Machine
TAIZHOU XUTIAN PACKING MACHINE CO.,LTDThe supplier hasn’t listed a price. We can get their current prices and MOQ.
Free quotes from independent agents · supplier checks approx. $5–$100 · 100% refund if not satisfied
About this product
- Materials: Iron
- Size: 1255*700*1400mm
- Color: Gray
- Exports to: Mainland China, Africa, Middle East, Southeast Asia, South Asia, Central Asia, USA and Canada, Latin America, Russia, EU, Other European Countries, Japan and South Korea, Hong Kong China, Macao China and Taiwan China, Others
- Made in: Zhejiang, China
About this product
- Materials: Iron
- Size: 1255*700*1400mm
- Color: Gray
- Exports to: Mainland China, Africa, Middle East, Southeast Asia, South Asia, Central Asia, USA and Canada, Latin America, Russia, EU, Other European Countries, Japan and South Korea, Hong Kong China, Macao China and Taiwan China, Others
- Made in: Zhejiang, China
Product details
| Materials | Iron |
|---|---|
| Size | 1255*700*1400mm |
| Color | Gray |
Product details
| Materials | Iron |
|---|---|
| Size | 1255*700*1400mm |
| Color | Gray |
From the supplier
Built with durable spare parts and reliable electrical components. Germany Dunker Director current motor enables machine to start working as soon as power connected and No pre-heating and standby- time are required which will help save power consumption. Direct driving design guarantees a low maintenance. Reading tension percentage and heater temperature from the control panel. Faults happen statistics are stored for maintenance analysis.
Specification：
Product name High speed Strapping Machine Model No Q80SC Motor SERVO MOTOR Strap tape PP strap Strap specification Width 5/9/12/15mm,thickness 0.35-0.65mm Arch size(W*H) 800 x 600mm(accpet customized) Strapping size Max 800 x 550 Min 100 x50mm (W800 x H600mm) Power 220V、50HZ、500W Control system PLC+Touch screen Strapping speed 1.1 seconds/strap Tension 10-400N Table height 750-800mm Welding method Heat sealing
Product Features and Advantages
High speed up to 1.1 seconds/strap
Auto Feeding
Direct motor driving,No belts.
Temperature and tension are displayed from screen
Germany Dunker servo motor, Save power and safe.
Loop ejecting and re-feed function
Instant heating system, persistent temperature
Tension mode: Fixed tension and Fixed length
Switchable Manual and Auto operation
With counting function
One button to clear strap jam
Built for 24 hours continuous operation
Quick strap loading operation
No tooling required for maintenance
No maintenance for Gear box
Tension adjustment: Very easy from control panel
Easy strap loading and unloading
Front and rear pedal operation
From the supplier
Built with durable spare parts and reliable electrical components. Germany Dunker Director current motor enables machine to start working as soon as power connected and No pre-heating and standby- time are required which will help save power consumption. Direct driving design guarantees a low maintenance. Reading tension percentage and heater temperature from the control panel. Faults happen statistics are stored for maintenance analysis.
Specification：
Product name High speed Strapping Machine Model No Q80SC Motor SERVO MOTOR Strap tape PP strap Strap specification Width 5/9/12/15mm,thickness 0.35-0.65mm Arch size(W*H) 800 x 600mm(accpet customized) Strapping size Max 800 x 550 Min 100 x50mm (W800 x H600mm) Power 220V、50HZ、500W Control system PLC+Touch screen Strapping speed 1.1 seconds/strap Tension 10-400N Table height 750-800mm Welding method Heat sealing
Product Features and Advantages
High speed up to 1.1 seconds/strap
Auto Feeding
Direct motor driving,No belts.
Temperature and tension are displayed from screen
Germany Dunker servo motor, Save power and safe.
Loop ejecting and re-feed function
Instant heating system, persistent temperature
Tension mode: Fixed tension and Fixed length
Switchable Manual and Auto operation
With counting function
One button to clear strap jam
Built for 24 hours continuous operation
Quick strap loading operation
No tooling required for maintenance
No maintenance for Gear box
Tension adjustment: Very easy from control panel
Easy strap loading and unloading
Front and rear pedal operation
