Introduction

KC-2709 Palm Scope has been designed as a user friendly and economical way of solving hidden problems and increasing productivity. (E.g. Inspect vent pipe and system of air conditioner, machine equipment, engine and so on).

KC-2709 has 2.7 " LCD screen, equipped with camera probe of 9mm head , length 60cm. The camera head of the probe has 4 bright LED lights that are unadjustable, which helps you to reach gaps and holes. The camera head equips with several accessories including magnetic tip, mirror tip and hook,which makes it flexible.

KC-2709 has features of 4X image zoom and 180°image rotation. The camera probe adopts unique patent structure which designs the camera probe in a built-in style. The product uses TPR and equips with safety sling and nylon bag which has a hanging buckle. It also has the advantages of small size、stable performance、easy operation and portability. It is widely used in applications such as the industry, the building, the aviation, the vehicles maintenance.

Specifications

Name

Palm Scope

Model

KC-2709

Recommended use

Indoor

Viewable angle

60°

Focal length

50mm

Visible distance

2.5cm-30cm

Diameter of camera head

Φ9mm

Probe length

About 60cm

Image display

2.7″TFT/LCD

LCD resolution

320×240 pixels

Image rotation

180°

Image zoom

1.0～4.0x

Protection level

Probe and camera head IP67

Light source

4 Ultra high brightness LED

Accessory

Mirror, Hook, Magnet, Thread protector and safety sling

Power supply

4pcs of AAA alkaline or rechargeable batteries (LR03 or KR03) , not included;

Battery continuous working time

>3 hours

Working temperature

0℃～45℃

Working humidity

5%～95%RH non-condensing

Storage Condition

-20℃～+60℃，≤85%（w/o batteries）

Main body dimension

136mm（180mm）×73mm×38mm

Main body weight

About 255g（w/o batteries）
