About this product
- Materials: Steel
- Size: 3245*1430*2270mm
- Color: Yellow
- Engine capacity: Other
- Horsepower: Other
- Load capacity: Other
- Exports to: Mainland China, Africa, Middle East, Southeast Asia, South Asia, Central Asia, USA and Canada, Latin America, Russia, EU, Other European Countries, Japan and South Korea, Hong Kong China, Macao China and Taiwan China, Others
- Made in: Anhui, China
About this product
- Materials: Steel
- Size: 3245*1430*2270mm
- Color: Yellow
- Engine capacity: Other
- Horsepower: Other
- Load capacity: Other
- Exports to: Mainland China, Africa, Middle East, Southeast Asia, South Asia, Central Asia, USA and Canada, Latin America, Russia, EU, Other European Countries, Japan and South Korea, Hong Kong China, Macao China and Taiwan China, Others
- Made in: Anhui, China
Product details
| Materials | Steel |
|---|---|
| Size | 3245*1430*2270mm |
| Color | Yellow |
| Engine capacity | Other |
| Horsepower | Other |
| Load capacity | Other |
| Tire certification | Other |
| Drive wheel | Other |
| Power source | Other |
Product details
| Materials | Steel |
|---|---|
| Size | 3245*1430*2270mm |
| Color | Yellow |
| Engine capacity | Other |
| Horsepower | Other |
| Load capacity | Other |
| Tire certification | Other |
| Drive wheel | Other |
| Power source | Other |
From the supplier
This is the description of 5.0T LPG&Gasoline Forklift
5.0 Ton LPG&Gasoline Forklift, is one kind of Big Ton Forklift,the power is LPG or both. Every big ton forklift standard equipped front double tyre. It`s more clean than Diesel Forklift, and can work longer than Electric Forklift.
Improved Safety Reliability
Half shaft sealing technology on drive axle end improves sealing reliability and reduces after-sale service cost.
Clearance buffering structure on lifting cylinder bottom makes goods lowering stable and improves working safety.
Efficient Double Fuel Engine
Original imported Japanese Nissan K21 / K25 engine with high performance. USA PSI EPA certified engine also available.
Wide View Mast Design
Wide view mast design, ensure the driver has an excellent view, which makes loading and unloading operations more secure and efficient.
Swing-down LPG Tank Bracket
With the ergonomics design, the LPG tank bracket is easily installed and swing down to a lower position with minimal effort.
Excellent LPG Convertor
Original imported USA IMPCO brand LPG convertor guarantee the safety of the forklift during operation and economic LPG fuel consumption.
1
Model
FY50
2
Power Type
LPG
3
Rated Capacity
kg
5000
4
Load Centre
mm
600
Characteristic & Dimension
5
Fork Size
Lift Height
mm
3000
6
L*W*T
mm
1220*150*60
7
Mast Tilt Angle
F/R
Deg
6°/12°
8
Front Overhang (Wheel centre to fork face)
mm
590
9
Ground Clearance (Bottom of mast)
mm
200
10
Overall Dimension
Length to face of fork (without fork)
mm
3450
11
Overall Width
mm
2010
12
Mast Lowered Height
mm
2500
13
Mast Extended Height (With backrest)
mm
4415
14
Overhead Guard Height
mm
2470
15
Turning Radius (outside)
mm
3250
16
Min.insecting aisle
mm
2960
Performance
17
Speed
Travel (Empty load)
km/h
30
18
Lifting (Full load)
mm/s
500
19
Max.Gradeability
%
20
Chassis
20
Tire
Front
8.25-15-14PR
21
Rear
8.25-15-14PR
22
Wheelbase
mm
2250
23
Service weight
kg
8150
Power & Transmission
24
Battery
Voltage/Capacity
V/Ah
(12/80)*2
25
Engine
Model
PSI4.3
26
Manufacture
America
27
Rated output/r.p.m.
kw
77.6/2300
28
Rated torque/r.p.m.
N·m
324/1700
29
No.of Cylinder
6
30
Bore*Stroke
mm
101.6×88.39
31
Displacement
cc
4294
32
Fuel Tank Capacity
L
140
33
Transmission
Type
Hydraulic
34
Stage (FWD/RVS)
2/2
35
Operating Pressure for Attachment
Mpa
19
