45 Ton Reach Stacker

10/10 fairsIndustry and Trade CompanyModel FD450
45 Ton Reach Stacker
Price on request

The supplier hasn’t listed a price. We can get their current prices and MOQ.

Service
From $29 per supplier (Verify)
You get
Phone and video verification, a quote sheet and a written report
Turnaround
3 business days
Contact details
Sent to you once your request is confirmed

If we can't reach the supplier within 3 business days, we refund the fee.

About this product

  • Materials: Steel
  • Size: 11373*6042*4650mm
  • Color: Yellow
  • Tire certification: Other
  • Drive wheel: Other
  • Power source: Other
  • Exports to: Mainland China, Africa, Middle East, Southeast Asia, South Asia, Central Asia, USA and Canada, Latin America, Russia, EU, Other European Countries, Japan and South Korea, Hong Kong China, Macao China and Taiwan China, Others
  • Made in: Anhui, China

Product details

MaterialsSteel
Size11373*6042*4650mm
ColorYellow
Tire certificationOther
Drive wheelOther
Power sourceOther
Engine capacityOther
Load capacityOther
HorsepowerOther

From the supplier

GS 45Ton Reach Stacker Features:

1, World-class ergonomic layout

2, U.S.A Cummins low speed and high torque engine

3, Capacity 45 Ton suitable for almost dutys work in port.


Energy efficient

1, All imported hydraulic system

2, Energy-saving LED light source

3, 10% reduction in fuel consumption


Maintenance and convenience

1, Open chassis design

2, Panoramic cab and can move back and forth as a whole.



ParameterUnitDataMax.Loadt45Outreach and lift weightOutreach (1st row,between front edge of tyre and middle of container)mm1900+830Lift weightt45Outreach (2nd row,between front edge of tyre and middle of container)mm3850+830Lift weightt31Outreach (3rd row,between front edge of tyre and middle of container)mm6350+830Lift weightt15Max.Hoisting Heightmm15100Max.Titl Angle°60Max.Hoisting Speed(Non-load/Load)mm/s240/210Max.Descending Speed(Non-load/Load)mm/s340/300Overall Lengthmm11373Overall Widthmm6042/4220Overall Heightmm4650Wheel Basemm6000Track Width(Front/Rear)mm3030/2750Min.Turning Radiusmm8200Min.Ground Clearance(Non-load)mm360Overall Weight(Non-load)kg72000Front Axle Load Capacity(Non-load/Load)kg28547/94023Rear Axle Load Capacity(Non-load/Load)kg43453/22977Max.Travel Speed(Non-load/Load)km/h25/22Max.Grade Ability(Non-load/Load)%25/20Diesel EngineManufacturer—CumminsModel—Turbo ChargingRated Powerkw/rpm250/2100TransmissionManufacturer—DANAModel—Counter ShaftOperation Way—Electro Hydraulic ShiftGear(Forward/Backward)—Front 4/Rear 4  Drive AxleManufacturer—OMCI or KESSLERModel—101.2447.3aSteering AxleModel—Transverse Cylinder,WeldingBraking SystemService Brake Type—Wet Multi-disc BrakesService Brake Adjust Type—HydraulicParking Brake Type—Caliper Disc BrakeParking Brake Operate Type—MechnicalTyreManufacturer—ZHONGCEFront Tyre Model/Q'ty—18.00-25-44/4Rear Tyre Model/Q'ty—18.00-25-44/2Air PressureMPa1.1SpreaderManufacturer—ELMEMax.Loadt45Rotation Angle°Clockwise:105      Counter Clockwise:195Lateral Driftmm±800CabinMovable
