About this product
- Materials: Steel
- Size: 3560*2010*2500mm
- Color: Yellow
- Load capacity: 1-10t
- Power source: Other
- Tire certification: ISO
- Exports to: Mainland China, Africa, Middle East, Southeast Asia, South Asia, Central Asia, USA and Canada, Latin America, Russia, EU, Other European Countries, Japan and South Korea, Hong Kong China, Macao China and Taiwan China, Others
- Made in: Anhui, China
About this product
- Materials: Steel
- Size: 3560*2010*2500mm
- Color: Yellow
- Load capacity: 1-10t
- Power source: Other
- Tire certification: ISO
- Exports to: Mainland China, Africa, Middle East, Southeast Asia, South Asia, Central Asia, USA and Canada, Latin America, Russia, EU, Other European Countries, Japan and South Korea, Hong Kong China, Macao China and Taiwan China, Others
- Made in: Anhui, China
Product details
| Materials | Steel |
|---|---|
| Size | 3560*2010*2500mm |
| Color | Yellow |
| Load capacity | 1-10t |
| Power source | Other |
| Tire certification | ISO |
| Drive wheel | Other |
| Horsepower | Other |
| Engine capacity | Other |
From the supplier
GS 7.0T LPG forklift adopts the newest technologies and ergonomic concepts in designing and manufacturing. The forklift with low cost of ownership, superior visibility, unmatched technique, safety and ergonomics designing for operator. It can be widely used in warehouse, factory, port and construction plant, etc.
Engine and transmission system
The forklift with Japanese level TCM technology transmission which ensure the high efficiency power transfer and performance.
The US PSI convert system highly improve the efficiency of the converting process and being a continuing support to the forklift performance.
Electrical system
Light indication / LCD display provides extensive information on truck operation and maintenance, it is with waterproof and shock proof protection. The advanced wiring harness, waterproof connectors and multiunit fuse module ensure the security and reliability of the circuit.
Optional LED lights can provide a better lighting environment and reduces the power consumption.
Hydraulic system
GS forklift equipped with high quality multi valves and gear pump and Japanese NOK sealing elements. The high quality hydraulic components and rational distribution of the pipes helps to control the oil pressure and highly improved the forklift performance.
Exhaust and cooling system
GS adopts the large capacity radiator and optimized heat dissipation channel. The combination of engine coolant and transmission fluid radiator is designed for maximum air flow passing through the counterweight.
The exhaust comes from the end face of muffler, using external type sparkle arrester, the exhaust resistance is greatly reduced, the function of smoke and fire extinguisher is more reliable. Particle soot filter and catalytic converter devices is optional device to improve the exhausting performance.
Steering and brake system
Steering axle adopts shock-mitigating device, it is install a up and down type steering rod with simple structure and better intensity and its both ends adopt joint bearing which enhanced the installation hole .
1
Model
FY70
2
Power Type
LPG
3
Rated Capacity
kg
7000
4
Load Centre
mm
600
Characteristic & Dimension
5
Fork Size
Lift Height
mm
3000
6
L*W*T
mm
1220*150*60
7
Mast Tilt Angle
F/R
Deg
6°/12°
8
Front Overhang (Wheel centre to fork face)
mm
595
9
Ground Clearance (Bottom of mast)
mm
200
10
Overall Dimension
Length to face of fork (without fork)
mm
3560
11
Overall Width
mm
2010
12
Mast Lowered Height
mm
2500
13
Mast Extended Height (With backrest)
mm
4415
14
Overhead Guard Height
mm
2470
15
Turning Radius (outside)
mm
3350
16
Min.insecting aisle
mm
3040
Performance
17
Speed
Travel (Empty load)
km/h
30
18
Lifting (Full load)
mm/s
460
19
Max.Gradeability
%
200
Chassis
20
Tire
Front
8.25-15-14PR
21
Rear
8.25-15-14PR
22
Wheelbase
mm
2250
23
Service weight
kg
9750
Power & Transmission
24
Battery
Voltage/Capacity
V/Ah
(12/80)*2
25
Engine
Model
PSI4.3
26
Manufacture
America
27
Rated output/r.p.m.
kw
77.6/2300
28
Rated torque/r.p.m.
N·m
324/1700
29
No.of Cylinder
6
30
Bore*Stroke
mm
101.6*88.39
31
Displacement
cc
4294
32
Fuel Tank Capacity
L
140
33
Transmission
Type
Hydraulic
34
Stage (FWD/RVS)
2/2
35
Operating Pressure for Attachment
Mpa
19
