About this product
- Materials: Q345R
- Size: 11000*2200*2500
- Color: Per customer request
- Exports to: Mainland China, Africa, Middle East, Southeast Asia, South Asia, Central Asia, USA and Canada, Latin America, Russia, EU, Other European Countries, Japan and South Korea, Hong Kong China, Macao China and Taiwan China, Others
- Made in: Zhejiang, China
About this product
- Materials: Q345R
- Size: 11000*2200*2500
- Color: Per customer request
- Exports to: Mainland China, Africa, Middle East, Southeast Asia, South Asia, Central Asia, USA and Canada, Latin America, Russia, EU, Other European Countries, Japan and South Korea, Hong Kong China, Macao China and Taiwan China, Others
- Made in: Zhejiang, China
Product details
| Materials | Q345R |
|---|---|
| Size | 11000*2200*2500 |
| Color | Per customer request |
Product details
| Materials | Q345R |
|---|---|
| Size | 11000*2200*2500 |
| Color | Per customer request |
From the supplier
Item and description
Specifcation
Quantity
Remarks
1
Dimension of skid
6500*2000*2500mm
1
2
horizontal Cylindrical lpg Tank
Water capacity: 5MT
Design code: China Standard,GB/T 19238-2003
Design approval: Third party inspection agency
Design pressure: 17.5 Kg/cm2
Design Temperature: -27 Deg C to +55 Deg
CHydro test pressure: 22.75 Kg/cm2 g
Tank Dimension: Ø1.8M x Overall Length Varies asper Tank capacity
1
3Dial-type Level Gauge(ROCHESTER)
Dial - 4” Dial
Display - Level in mm, Accuracy - 1-2%
Make: Bluesky
14Magnetic Flap Level Gauge
Can communicate with our managemeny system
15LWB-150 LPG Turbine Pump
LWB-150 LPG Turbine Pump
Inlet: 1.5“
Outlet: 1"
Speed: 60Hz 3450 RPM or 50Hz 2880 RPM
Max.Working Pressure: 27.6 bar(400PSI)
Max.Differential Pressure: 17.2bar(250PSI)
Max./Min.Temperature: -32℃～107℃
Power of Motor: 5Kw
16
LPG dispenser single nozzle RT-LPG124A
EX PROOF
(CAN USE FOR COOKING CYLINDER AND CAR CYLINDER )
Filling flow rate: 35LPM
1 x Air separator
1 x 4-pistion flow meter
2 x LPG filling nozzle
1 x LPG hose with length of 4.5Meter
1 x Electronic calculator with1 keyboard and 1 display board
Painting body
17TEMP-PRESSURE GAUGE
Temperature Gauges, Pressure Gauges,
Differential pressure switch for Pump, High-level
alarm switch and other instruments.
1
8LPG CONTROL PANEL
LPG Control Panel for making interface among
Dispensing Pump, Dispenser, LPG cylinder filling,
Tank level Gauging, Unloading Pump, Control Valves& safety interlocking etc.
1
9ALL VALVE
Ball Valves, Strainer, Emergency Shutdown
Valve,Check Valve,Bypass-Valve,Safety Valve, Flame
Arrester and other accessories including Tank
installation frame mounting, painting etc
37
10PIPE & INSTALLATION
Pipe, Pipefittings and other accessories including
supply, welding, testing and mechanical
installation including Tank installation skid/frame
mounting facility, painting etc.
Tank will be installed on 360° Degree Protection
Frame
1
11Weight Scale
RATED WEIGHT :0-150KG
112AIR COMPRESSOR
Air Compressor & Accessories for pneumatic
operation of entire skid
Power:0.85KW
113LPG compressor for discharging
LPG compressor Model ZW-1.0/10-16
Media: LPG gas
Cooling type: Wind cool
Compressing stage: 1
Capacity: 1.0 m3/min
Inlet pressure: 1.0Mpa
Outlet pressure 1.6Mpa
Speed: 650 RPM
EX motor: 11kw,380V 50HZ
Packge: Wooden case
Dimension: 1220*680*960
Weight:450K
1
