X6132 Universal Lift Table Milling Machine Technical Agreement

Party A:

Party B: Nantong Lilian Machine Tool Manufacturing Co., Ltd.

Party A purchased X6132 universal lifting table milling machine from Party B, and after negotiation, Party A and Party B reached the following technical agreement:

1. Equipment name, structural form, technical parameters, other descriptions:

(1) Equipment name: X6132 universal lifting table milling machine

Purpose: Metal cutting

(2) Structural form: universal lifting table milling machine

(3) See Annex 1 for technical parameters.

(4) Other explanations:

1. The equipment is reasonably designed, well manufactured, stable and reliable in performance, easy to use and maintain, beautiful in shape, reasonable motor power, low noise, long service life, and does not pollute the environment.

2. Party B must list the details of the accompanying attachments, including the name, model and quantity of the attachments.

3. Equipment safety signs shall be red.

4. Easy to maintain, repair and use.

5. The equipment must have necessary safety protection facilities and be environmentally friendly and energy-saving.

2. Provide technical documents:

Party B shall provide equipment instruction 1, which is attached to the machine tool.

Equipment electrical principles, wiring diagram 1, are included with the machine tool.

Equipment technical qualification specification 1 is attached to the machine tool.

1 copy of the packing list, Attachment 2.

Machine tool foundation drawing, annex 3.

3. Schedule and requirements:

Party B is responsible for delivering goods within 20 working days after the contract is signed and effective.

4. Equipment acceptance:

Acceptance basis: technical agreement, contract and relevant national standards for execution.

The following standards will be implemented during the design and manufacturing process of machine tools

GB3933.3-2002 Accuracy of lifting table milling machines

JB/T2800-92 Technical requirements for lifting table milling machine

GB15760-2004 General technical conditions for safety protection of metal cutting machine tools

GB5226.1-2002 Safety of machinery-Mechanical electrical equipment-Part 1: General technical conditions

V. Transportation

Party B is responsible for transporting the equipment to Party A's location, and Party B is responsible for the freight. The products provided by Party B to Party A shall be properly packed. If damage to the products is caused by packaging and transportation, Party B shall be responsible.

6. After-sales service

1. The "three guarantees" period of equipment quality in China is twelve months. If quality problems are discovered during the use of equipment by Party A, a reply shall be made or maintenance personnel shall be dispatched within 24 hours after receiving Party A's notice.

2. After passing the acceptance, Party B shall be responsible for repairing non-human quality problems arising from the equipment during the warranty period. Outside the "Three Guarantees" period, Party B provides lifelong maintenance services.

This agreement is made in duplicate, with Party A holding one and Party B holding one; as an annex to the contract, it has the same legal effect as the contract, and will be signed by both parties.

Party A: Party B: Nantong Lili Machine Tool Manufacturing Co., Ltd.

Product parameters of Nantong Lilian Machine Tool Manufacturing Co., Ltd.

Parameters of X6132 universal lifting table milling machine

Project name Working table

Unit Unit Parameter Specification

workbench
working Table

Working area (W×L) Working surface(W×L) mm 320×1325 Maximum carrying weight Bearing kg 500 No. of T-slots of table a 3 Width of T-slots of table mm 18 Distance between T-slots mm 70 Max.swivel angle dep ±45

stroke
Travels

X-direction (workbench longitudinal) Manual/motorized Longitudinal(manual/auto) mm 700/680 Y direction (skid lateral) manual/motorized
Cross (manual/auto) mm 250/240 Z direction (vertical direction of lift table) Manual/motorized Vertical(manual/auto) mm 320/300

spindle
Spindle

Taper IOS7: 24 NO.50 speed range r/min 30-1500 No. of spindle speeds Level Step 18 spindle Bore Dia mm 29

Minimum/maximum distance from vertical guide surface to workbench centerline axis

Distance from spindle nose to table surface min./ mix.

mm

215/470

Distance from the center line of the spindle to the vertical guide surface of the bed

Distance from centre line of spindle tovertical guideway surface of column

mm

30/350

feed
Feedrates

cutting feed rate mm/min

X:23.5~1180 Y:15~786

Z :8~ 394

Rapid feed rate mm/min X,y:2300 z:770 No. of feeds Level Step 18

motor
Motor

Power of spindle motor kw 7.5 powerof feed motor kw 2.2

other
Others

Overall size of machine tool (length × width × height) Overall dimensions (L×W×H) mm 2294×1770×1665 Net weight of the machine(approximately) kg 2800

X6132 (62w) milling machine partial internal parts list

Electrical:

2.2KW motor, Wannan motor

Travel switch: Beijing No. 1 Machine Tool Electrical Factory

AC contactor: Shanghai Tianshui 213

Thermal relay: Shanghai Tianshui 213

Circuit breaker: Shanghai Tianshui 213

Bearing: Harbin Bearing

Spindle braking electromagnetic clutch: Beijing No. 1 Machine Tool Electrical Factory

The control box and feed box are the same supplier as Beijing No. 1 Machine Tool, which is based in Zibo, Shandong Province.

gear: Shenyang Machine Tool Gear Branch

X6132

packing list

total 2 page

page 1

Factory number: Volume:

Contract number: Gross weight:

Box No.: Weight: 2800kg

Shipping mark:

1. X6132 universal lifting table milling machine

II. Annexes

serial number

names

specifications

number

remark

1

double-ended wrench

single-ended wrench

17×19，22×24

27×30，32×36

14

1 piece each

S91-1

S91-2

2

Allen key 5 .8 .10

1 piece each

S91-7

3

Electrical box wrench

1 payment

62W845A

4

pull rod M24×700

1 set

B1S63 -1 (1 piece each for tie rod, nut and back nut

5

anchor bolts

washer

the nut

M20×500

20

M20

4 pieces

4 pieces

4 pieces

6

oil gun

1 piece

7

lighting bulb AC24V 40W

1 piece

8

milling cutter spindle body φ22

1 set

B1S61 -6 (1 mandrel body, 14 rings, 1 sleeve)

9

milling cutter spindle body φ27

1 set

B1S61 -6 (1 piece mandrel body, 14 pieces rings, 1 piece sleeve

10

milling cutter spindle body φ32

1 set

B1S61 -6 (1 mandrel body, 13 rings, 1 sleeve)
