About this product
- Materials: Cast stainless steel
- Size: 1280x525x850
- Exports to: Mainland China, Africa, Middle East, Southeast Asia, South Asia, Central Asia, USA and Canada, Latin America, Russia, EU, Other European Countries, Japan and South Korea, Hong Kong China, Macao China and Taiwan China, Others
About this product
- Materials: Cast stainless steel
- Size: 1280x525x850
- Exports to: Mainland China, Africa, Middle East, Southeast Asia, South Asia, Central Asia, USA and Canada, Latin America, Russia, EU, Other European Countries, Japan and South Korea, Hong Kong China, Macao China and Taiwan China, Others
Product details
| Materials | Cast stainless steel |
|---|---|
| Size | 1280x525x850 |
Product details
| Materials | Cast stainless steel |
|---|---|
| Size | 1280x525x850 |
From the supplier
I Description:
This model is specially designed for lab, easy maintenance, good sealing, no leakage, corrosion resisting and good heating efficiency
Working Principle:
Main motor drive two blades to do a reverse direction rotation in the trough through the reducer slowdown. Reverse direction rotation by the blade brings shear stress between the two blades and the blades with trough, reach an effect to mix, knead, crush and disperse the materials. Discharge the material through tilting trough by hydraulic cylinder.
II Main technical parameters:
No.
Parameters
NHZ-5
1
Whole capacity
6 L
2
Working capacity
4L
3
Power of main motor
1.5kW/AC380V/50Hz
4
Reducer(gear unit)
BWD1-23-1.5
5
Blade type
Double Sigma blades
6
Material of blade
Cast stainless steel
7
Material of shaft
Stainless steel
8
Revolution of blade
front/rear 63/43rpm
9
Distance between blade and trough
Less than 2 mm
10
Distance between blade and trough end
Less than 2 mm
11
Packing of shaft
PTFE
12
Heating way
electric heating 1.5kW or by steam
13
Discharging way
Tilt trough manual
14
Angle of tilting trough
Approx.95°
15
Open lid
manual
16
Seal of lid
viton
17
Limit vacuum
-0.09MPa
18
Water loop vacuum pump
XD-20
19
Speed bleeding air
20m3/h
20
coating
High quality epoxy based paint.
21
Appearance of size( L×W×H )
Approx.1280×525×850
From the supplier
I Description:
This model is specially designed for lab, easy maintenance, good sealing, no leakage, corrosion resisting and good heating efficiency
Working Principle:
Main motor drive two blades to do a reverse direction rotation in the trough through the reducer slowdown. Reverse direction rotation by the blade brings shear stress between the two blades and the blades with trough, reach an effect to mix, knead, crush and disperse the materials. Discharge the material through tilting trough by hydraulic cylinder.
II Main technical parameters:
No.
Parameters
NHZ-5
1
Whole capacity
6 L
2
Working capacity
4L
3
Power of main motor
1.5kW/AC380V/50Hz
4
Reducer(gear unit)
BWD1-23-1.5
5
Blade type
Double Sigma blades
6
Material of blade
Cast stainless steel
7
Material of shaft
Stainless steel
8
Revolution of blade
front/rear 63/43rpm
9
Distance between blade and trough
Less than 2 mm
10
Distance between blade and trough end
Less than 2 mm
11
Packing of shaft
PTFE
12
Heating way
electric heating 1.5kW or by steam
13
Discharging way
Tilt trough manual
14
Angle of tilting trough
Approx.95°
15
Open lid
manual
16
Seal of lid
viton
17
Limit vacuum
-0.09MPa
18
Water loop vacuum pump
XD-20
19
Speed bleeding air
20m3/h
20
coating
High quality epoxy based paint.
21
Appearance of size( L×W×H )
Approx.1280×525×850
