About this product
- Materials: mild steel
- Size: 3700*1600*1900
- Color: white and green
- Exports to: Mainland China, Africa, Middle East, Southeast Asia, South Asia, Central Asia, USA and Canada, Latin America, Russia, EU, Other European Countries, Japan and South Korea, Hong Kong China, Macao China and Taiwan China, Others
- Made in: Shanghai, China
About this product
- Materials: mild steel
- Size: 3700*1600*1900
- Color: white and green
- Exports to: Mainland China, Africa, Middle East, Southeast Asia, South Asia, Central Asia, USA and Canada, Latin America, Russia, EU, Other European Countries, Japan and South Korea, Hong Kong China, Macao China and Taiwan China, Others
- Made in: Shanghai, China
Product details
| Materials | mild steel |
|---|---|
| Size | 3700*1600*1900 |
| Color | white and green |
Product details
| Materials | mild steel |
|---|---|
| Size | 3700*1600*1900 |
| Color | white and green |
From the supplier
1. According to JB/T 2257.2 92 "sheet metal bending machine technical conditions" and GB/T 14349-93, the precision of sheet metal bending machine for the machine design, all parts of the machine adopts computer aided design, computer finite element analysis and calculation, computer aided manufacture (CAD/CAE/CAM) software for structural design, fully ensure the structural strength and stiffness of each parts;
2. The whole steel plate welded structure, thick and solid frame, high rigidity, good property of shock absorption;
3. The mechanical structure of the machine is mainly composed of frame, a workbench, slider, and block-stop the main cylinder and parts. Perfect design and manufacturing technology, can effectively ensure the accuracy of the machine tool manufacture and use. The main structure of the manufacturing process (process test of) :
Sheet metal warehousing physical and chemical inspection sheet metal pretreatment (blasting except embroidered) NC flame cutting blanking machining various compound gas protection welding joint surface vibration aging + tempering process large floor boring and milling machine and other mechanical processing process assembling finished products;
4.adopt up moving bending machine design, the work is smooth, easy operation, safety;
5. The machine's frame, the slider, table and other major parts are using large floor boring and milling machine a loading card finishing, ensure the various geometrical precision of the host requirements;
Name
Data
Unit
axis
X,Y,V
Nominal pressure
1000
KN
Length of working table
3200
mm
Distance between frames
2600
mm
Ram stroke
150
mm
Throat depth
320
mm
Max open height
400
mm
Back gauge range
600
mm
thickness of side frame
50
mm
thickness of front frame
80
mm
Thickness of workbench
80
mm
Ram speed
Rapid down(No load)
80
mm/s
Run(Full load)
8
mm/s
return
60
mm/s
pump
20
L/min
Pump model
HG1-20-01R-VPC
Main motor Power
7.5
kw
Bending angle error range
＜1
°
Dimension
About 3600*1500*2420
mm
From the supplier
1. According to JB/T 2257.2 92 "sheet metal bending machine technical conditions" and GB/T 14349-93, the precision of sheet metal bending machine for the machine design, all parts of the machine adopts computer aided design, computer finite element analysis and calculation, computer aided manufacture (CAD/CAE/CAM) software for structural design, fully ensure the structural strength and stiffness of each parts;
2. The whole steel plate welded structure, thick and solid frame, high rigidity, good property of shock absorption;
3. The mechanical structure of the machine is mainly composed of frame, a workbench, slider, and block-stop the main cylinder and parts. Perfect design and manufacturing technology, can effectively ensure the accuracy of the machine tool manufacture and use. The main structure of the manufacturing process (process test of) :
Sheet metal warehousing physical and chemical inspection sheet metal pretreatment (blasting except embroidered) NC flame cutting blanking machining various compound gas protection welding joint surface vibration aging + tempering process large floor boring and milling machine and other mechanical processing process assembling finished products;
4.adopt up moving bending machine design, the work is smooth, easy operation, safety;
5. The machine's frame, the slider, table and other major parts are using large floor boring and milling machine a loading card finishing, ensure the various geometrical precision of the host requirements;
Name
Data
Unit
axis
X,Y,V
Nominal pressure
1000
KN
Length of working table
3200
mm
Distance between frames
2600
mm
Ram stroke
150
mm
Throat depth
320
mm
Max open height
400
mm
Back gauge range
600
mm
thickness of side frame
50
mm
thickness of front frame
80
mm
Thickness of workbench
80
mm
Ram speed
Rapid down(No load)
80
mm/s
Run(Full load)
8
mm/s
return
60
mm/s
pump
20
L/min
Pump model
HG1-20-01R-VPC
Main motor Power
7.5
kw
Bending angle error range
＜1
°
Dimension
About 3600*1500*2420
mm
