Hydraulic press machine
Jiangsu Weiyang Heavy Industry Technology Co.,ltd
See what’s includedHide breakdown
- FOB goods (100)
- $450,500,000
- Ocean freight + handling (5.0 CBM, volume guessed from price)
- $1,300
- US duty (3.5%)
- $15,767,500
- Section 301 tariff (25.0%)
- $112,625,000
- Customs fees (MPF/HMF)
- $563,760
Estimate in USD to a US port using category averages, rates as of 2026-09. Other countries on request. A quote from your agent uses real carton sizes, freight and the exact tariff line.
- FOB goods (100)
- $450,500,000
- Ocean freight + handling (5.0 CBM, volume guessed from price)
- $1,300
- US duty (3.5%)
- $15,767,500
- Section 301 tariff (25.0%)
- $112,625,000
- Customs fees (MPF/HMF)
- $563,760
Estimate in USD to a US port using category averages, rates as of 2026-09. Other countries on request. A quote from your agent uses real carton sizes, freight and the exact tariff line.
Verify from $29 · written report in 3 business days · 100% refund if not satisfied
Hydraulic press machine
Jiangsu Weiyang Heavy Industry Technology Co.,ltdSee what’s includedHide breakdown
- FOB goods (100)
- $450,500,000
- Ocean freight + handling (5.0 CBM, volume guessed from price)
- $1,300
- US duty (3.5%)
- $15,767,500
- Section 301 tariff (25.0%)
- $112,625,000
- Customs fees (MPF/HMF)
- $563,760
Estimate in USD to a US port using category averages, rates as of 2026-09. Other countries on request. A quote from your agent uses real carton sizes, freight and the exact tariff line.
- FOB goods (100)
- $450,500,000
- Ocean freight + handling (5.0 CBM, volume guessed from price)
- $1,300
- US duty (3.5%)
- $15,767,500
- Section 301 tariff (25.0%)
- $112,625,000
- Customs fees (MPF/HMF)
- $563,760
Estimate in USD to a US port using category averages, rates as of 2026-09. Other countries on request. A quote from your agent uses real carton sizes, freight and the exact tariff line.
Verify from $29 · written report in 3 business days · 100% refund if not satisfied
About this product
- Materials: mild steel
- Size: 1400*1600*3500
- Color: light green
- Exports to: Mainland China, Africa, Middle East, Southeast Asia, South Asia, Russia, Others
- Made in: Jiangsu, China
About this product
- Materials: mild steel
- Size: 1400*1600*3500
- Color: light green
- Exports to: Mainland China, Africa, Middle East, Southeast Asia, South Asia, Russia, Others
- Made in: Jiangsu, China
Product details
| Materials | mild steel |
|---|---|
| Size | 1400*1600*3500 |
| Color | light green |
Product details
| Materials | mild steel |
|---|---|
| Size | 1400*1600*3500 |
| Color | light green |
From the supplier
I. Applications and Characteristics of the Machine
This press is suitable for pressing operations such as punching, pressing, stamping, bending, flanging and extrusion etc. of plasticity materials. It is also used for straightening, pressure assembling and molding of powder products as well as nonmetal materials such as plastics, insulator and abrasive products etc..
This press, with independent motive organization and electric system, adopts the control system of the centralized buttons, and controls technical operations with the relay to achieve adjustment (inching) and operation (semi-auto).
II、Main technical parameters
NO.
ITEM
UNIT
SPECIFICATION
1
Nominal force
kN
1600
2
Push up force
kN
400
3
Max. working pressure of fluid
MPa
25
4
Max. stroke of slide beam
mm
700
5
Max. stroke of push up piston
mm
200
6
Max. opening between worktable and slide beam
mm
1000
7
Slide-stroke speed
Down speed
mm/s
100
Pressing speed
mm/s
10~15
Back stroke speed
mm/s
70
8
Valid work table area
Left-right
mm
700
Front-back
mm
750
9
Motor power
kW
11
Remark
Shut up machine, pressure maintaining
Up die slowly back
Reserve two group oil-ways
With two temperature control module
From the supplier
I. Applications and Characteristics of the Machine
This press is suitable for pressing operations such as punching, pressing, stamping, bending, flanging and extrusion etc. of plasticity materials. It is also used for straightening, pressure assembling and molding of powder products as well as nonmetal materials such as plastics, insulator and abrasive products etc..
This press, with independent motive organization and electric system, adopts the control system of the centralized buttons, and controls technical operations with the relay to achieve adjustment (inching) and operation (semi-auto).
II、Main technical parameters
NO.
ITEM
UNIT
SPECIFICATION
1
Nominal force
kN
1600
2
Push up force
kN
400
3
Max. working pressure of fluid
MPa
25
4
Max. stroke of slide beam
mm
700
5
Max. stroke of push up piston
mm
200
6
Max. opening between worktable and slide beam
mm
1000
7
Slide-stroke speed
Down speed
mm/s
100
Pressing speed
mm/s
10~15
Back stroke speed
mm/s
70
8
Valid work table area
Left-right
mm
700
Front-back
mm
750
9
Motor power
kW
11
Remark
Shut up machine, pressure maintaining
Up die slowly back
Reserve two group oil-ways
With two temperature control module
