HK Crimp 80A 6pins heavy duty connector
ZHEJIANG CEREALS OILS & FOODSTUFFS IMP. & EXP. CO., LTD.
The supplier hasn’t listed a price. We can get their current prices and MOQ.
Verify from $29 · written report in 3 business days · 100% refund if not satisfied
HK Crimp 80A 6pins heavy duty connector
ZHEJIANG CEREALS OILS & FOODSTUFFS IMP. & EXP. CO., LTD.The supplier hasn’t listed a price. We can get their current prices and MOQ.
Verify from $29 · written report in 3 business days · 100% refund if not satisfied
About this product
- Materials: Polycarbonate
- Color: Grey
- Exports to: Southeast Asia, South Asia, USA and Canada, Latin America, Russia, EU, Other European Countries, Others
About this product
- Materials: Polycarbonate
- Color: Grey
- Exports to: Southeast Asia, South Asia, USA and Canada, Latin America, Russia, EU, Other European Countries, Others
Product details
| Materials | Polycarbonate |
|---|---|
| Color | Grey |
Product details
| Materials | Polycarbonate |
|---|---|
| Color | Grey |
From the supplier
SMICO heavy duty connector are extensively used in quipment that requires electrical and signal connections,such as mold,machinery,construction machinery, textile machinery,transportation technology,electric energy,electric locomotives and so on various need electrical and petrochemical electrical equipment.
Insert CoreShell Size: Matches 16B ShellConnector Pin CountNumber Of Contacts4/0 4/2+PE- Rated Current－Rated Current80ARelative Rated Voltage－Rated Voltage830VPhase-to-Phase Rated Voltage Rated Pulse Voltage－Rated Impulse Voltage8KV- Contamination Level－Pollution Degree3Or－Or —According to UL/CSA Rated Voltage－Rated Voltage Acc.to Ul CSA400VInsulation ResistanceInsulation Resistance≥1010ΩMaterialMaterialPolycarbonateworking temperature rangeLimiting Temperatures-40℃...+125℃Per UL94 Flame Retardant RatingFlammability Acc. To UL94V0Plug/Unplug TimesMecHEnical Working Life-mating Cycles≥500Pin InsertMaterialMaterialCopper AlloySurface TreatmentSurfaceSilver-Plated/Gold-PlatedContact ResistanceContact Resistance≤0.3mΩScrew Connection - Wire GaugeWire Gauge1.5-16mm2－AWGAWG16-6- Tightening TorqueTightening Torque0.5Nm
From the supplier
SMICO heavy duty connector are extensively used in quipment that requires electrical and signal connections,such as mold,machinery,construction machinery, textile machinery,transportation technology,electric energy,electric locomotives and so on various need electrical and petrochemical electrical equipment.
Insert CoreShell Size: Matches 16B ShellConnector Pin CountNumber Of Contacts4/0 4/2+PE- Rated Current－Rated Current80ARelative Rated Voltage－Rated Voltage830VPhase-to-Phase Rated Voltage Rated Pulse Voltage－Rated Impulse Voltage8KV- Contamination Level－Pollution Degree3Or－Or —According to UL/CSA Rated Voltage－Rated Voltage Acc.to Ul CSA400VInsulation ResistanceInsulation Resistance≥1010ΩMaterialMaterialPolycarbonateworking temperature rangeLimiting Temperatures-40℃...+125℃Per UL94 Flame Retardant RatingFlammability Acc. To UL94V0Plug/Unplug TimesMecHEnical Working Life-mating Cycles≥500Pin InsertMaterialMaterialCopper AlloySurface TreatmentSurfaceSilver-Plated/Gold-PlatedContact ResistanceContact Resistance≤0.3mΩScrew Connection - Wire GaugeWire Gauge1.5-16mm2－AWGAWG16-6- Tightening TorqueTightening Torque0.5Nm
