10 pin male and female connector Heavy duty connector machine connector
ZHEJIANG CEREALS OILS & FOODSTUFFS IMP. & EXP. CO., LTD.
The supplier hasn’t listed a price. We can get their current prices and MOQ.
Verify from $29 · written report in 3 business days · 100% refund if not satisfied
10 pin male and female connector Heavy duty connector machine connector
ZHEJIANG CEREALS OILS & FOODSTUFFS IMP. & EXP. CO., LTD.The supplier hasn’t listed a price. We can get their current prices and MOQ.
Verify from $29 · written report in 3 business days · 100% refund if not satisfied
About this product
- Materials: Polycarbonate
- Color: Grey
- Exports to: Southeast Asia, South Asia, USA and Canada, Latin America, Russia, EU, Other European Countries, Others
About this product
- Materials: Polycarbonate
- Color: Grey
- Exports to: Southeast Asia, South Asia, USA and Canada, Latin America, Russia, EU, Other European Countries, Others
Product details
| Materials | Polycarbonate |
|---|---|
| Color | Grey |
Product details
| Materials | Polycarbonate |
|---|---|
| Color | Grey |
From the supplier
SMICO heavy duty connector are extensively used in quipment that requires electrical and signal connections,such as mold,machinery,construction machinery, textile machinery,transportation technology,electric energy,electric locomotives and so on various need electrical and petrochemical electrical equipment.
Insert Core INSERT Shell Size: Matches 10AHoods & Housing: H10A
Connector Pin CountNumber Of Contacts10
- Rated Current－Rated Current16A
Relative Rated Voltage－Rated Voltage250V
Phase-to-Phase Rated Voltage 400V
Rated Pulse Voltage－Rated Impulse Voltage4KV
- Contamination Level－Pollution Degree3
Or－Or16A 250V 4kV 3
Per SpecUL/CSARated Voltage－Rated Voltage Acc.to Ul CSA600V
Insulation ResistanceInsulation Resistance≥1010Ω
MaterialMaterialPolycarbonate Polycarbonate
working temperature rangeLimiting Temperatures-40℃...+125℃
According ToUL94Flame Retardant GradeFlammability Acc. To UL94V0
Plug/Unplug TimesMecHEnical Working Life-mating Cycles≥500
Pin Insert CRIMP CONTACT
MaterialMaterialCopper Alloy Copper Alloy
Surface TreatmentSurfaceSilver Plated/Gold Plated Silver plated/Gold plated
Contact ResistanceContact Resistance≤1mΩ
Wiring MethodTerminalScrew Connection/SCREW TERMINAL
- Wire GaugeWire Gauge1.0-2.5mm2
－AWGAWG18-14
- Tightening TorqueTightening Torque0.25N·m
From the supplier
SMICO heavy duty connector are extensively used in quipment that requires electrical and signal connections,such as mold,machinery,construction machinery, textile machinery,transportation technology,electric energy,electric locomotives and so on various need electrical and petrochemical electrical equipment.
Insert Core INSERT Shell Size: Matches 10AHoods & Housing: H10A
Connector Pin CountNumber Of Contacts10
- Rated Current－Rated Current16A
Relative Rated Voltage－Rated Voltage250V
Phase-to-Phase Rated Voltage 400V
Rated Pulse Voltage－Rated Impulse Voltage4KV
- Contamination Level－Pollution Degree3
Or－Or16A 250V 4kV 3
Per SpecUL/CSARated Voltage－Rated Voltage Acc.to Ul CSA600V
Insulation ResistanceInsulation Resistance≥1010Ω
MaterialMaterialPolycarbonate Polycarbonate
working temperature rangeLimiting Temperatures-40℃...+125℃
According ToUL94Flame Retardant GradeFlammability Acc. To UL94V0
Plug/Unplug TimesMecHEnical Working Life-mating Cycles≥500
Pin Insert CRIMP CONTACT
MaterialMaterialCopper Alloy Copper Alloy
Surface TreatmentSurfaceSilver Plated/Gold Plated Silver plated/Gold plated
Contact ResistanceContact Resistance≤1mΩ
Wiring MethodTerminalScrew Connection/SCREW TERMINAL
- Wire GaugeWire Gauge1.0-2.5mm2
－AWGAWG18-14
- Tightening TorqueTightening Torque0.25N·m
