About this product
- Materials: carbon steel/SS304
- Exports to: Mainland China, Africa, Middle East, Southeast Asia, South Asia, Central Asia, USA and Canada, Latin America, Russia, EU, Other European Countries, Japan and South Korea, Hong Kong China, Macao China and Taiwan China
About this product
- Materials: carbon steel/SS304
- Exports to: Mainland China, Africa, Middle East, Southeast Asia, South Asia, Central Asia, USA and Canada, Latin America, Russia, EU, Other European Countries, Japan and South Korea, Hong Kong China, Macao China and Taiwan China
Product details
| Materials | carbon steel/SS304 |
|---|
From the supplier
This series of radar level meter adopted 26G high frequency radar sensor, the maximum measurement range can reach up to 70 meters. Antenna is optimized further processing, the new fast microprocessors have higher speed and efficiency can be done signal analysis, the instrumentation can be used for reactor, solid silo and very complex measurement environment.
Features- Small antenna size, easy to install; Non-contact radar, no wear, no pollution.
- Almost no corrosion, bubble effect; almost not affected by water vapor in the atmosphere, the temperature and pressure changes.
- Serious dust environment on the high level meter work has little effect.
- A shorter wavelength, the reflection of solid surface inclination is better.
- Beam angle is small, the energy is concentrated, can enhance the ability of echo and to avoid interference.
- The measuring range is large. A good measuring result will be got in the measuring process.
- High signal-to-noise ratio, the level fluctuation state can obtain better performance.
- High frequency, measurement of solid and low dielectric constant of the best choice.
Enter the finished product warehouse and wait for transportation
Model Suitable for Medium Measuring Range(meters) Temper-
ature Connection Process Pressure Measure-
ment
Precision
Other
901 All kinds of corrosive liquid 10 -40℃ ~ 120℃ Flange(optional)/Thread -0.1 ~ 0.3 MPa ±5mm Explosion-proof Grade:
Exia IIC T6 Ga
Frequency :26 GHz
The signal Output:(4 ~ 20) mA/HART (Two
wire/Four)RS485/Modbus
The Scene Display:4- digital LCD
Shell :Aluminum 902 Liquid 30 -40℃ ~ 150℃ Flange (optional) / Thread -0.1 ~ 4.0 MPa ±3mm 903 Solid material,Strong dust 70 -40℃ ~ 250℃ Universal Flange -0.1 ~ 0.1MPa ±15mm 904 Solid material,Strong dust 70 -40℃ ~ 250℃ Universal Flange -0.1 ~ 0.1MPa ±15mm 905 Solid particles,Powder 30 -40℃ ~ 250℃ Thread, Flange -0.1 ~ 4.0MPa ±10mm 906 Hygienic liquid
storage,corrosive container 20 -40℃ ~ 150℃ Flange -0.1 ~ 0.1MPa ±3mm
