APPLICATION

The automatic rotary paper plate making machine is mainly applied for producing molded pulp one-off plates for foodservice, disposable tableware, supermarket plates for fresh fruits and meat, food packaging items and so on.

 MAIN FEATURES

Pulp molding production line with automatic rotary paper plate making machine as the main system has the following features:

- Higher degree of automation with dry-press production
- Excellent performance of rotary forming technology
- Highly efficient 6-pass drying line specially designed for plates
- Match with auto conveying and auto hotpress system

 OUR ADVANTAGES

Worry-Free

Dry-press tableware production, no more trouble from hole blockage on hotpress molds;

Reliability

Applied with fully mechanical drive system, ensures reliable running permanently;

Durability

Main machine designed with complete casting parts and connected by bolts, secures its sturdiness and durability;

Cleaner

Largely use stainless steel surface, with indirect drying, ensuring cleaner products.

 MAIN SPECIFICATIONS

Model.

XZ8-19542

Structure

8 Faces Rotary Forming
1 Faces Pick-and-Place Transfer
With Forming Mold Washing and Product Flushing
 Mechanical Squeezing Press Mold on Top

Platen Size

1950 x 420 mm

Forming Type

Rotary Forming

Forming Cycle

≤ 20 Blowoff / min

No. of Molds

Each Face 6pcs  (based on 10" plate)

Max. Product Height

70 mm

Control By

PLC + Touchscreen

Designed Capacity

6000 pcs/hr  (based on 10" plate)

Remarks

* The above specification is for reference only, due to continuous technology development, data will be updated from time to time.
* Pulp Molding Equipments are non-standard equipments, we are able to provide customized solution according to specific requirements from customer.
* Welcome to contact us anytime, our professional team will provide more effective help and supports for you.
