About this product
- Size: 12035
- Color: Blue
- Control type: Other
- Layout: Horizontal
- Certification: CEISO
- Customized: Customized
- Exports to: Middle East, Southeast Asia, Central Asia, Russia, Japan and South Korea, Hong Kong China, Macao China and Taiwan China
About this product
- Size: 12035
- Color: Blue
- Control type: Other
- Layout: Horizontal
- Certification: CEISO
- Customized: Customized
- Exports to: Middle East, Southeast Asia, Central Asia, Russia, Japan and South Korea, Hong Kong China, Macao China and Taiwan China
Product details
| Size | 12035 |
|---|---|
| Color | Blue |
| Control type | Other |
| Layout | Horizontal |
| Certification | CEISO |
| Customized | Customized |
| Automatic grade | Other |
Product details
| Size | 12035 |
|---|---|
| Color | Blue |
| Control type | Other |
| Layout | Horizontal |
| Certification | CEISO |
| Customized | Customized |
| Automatic grade | Other |
From the supplier
"Floor rail type bed design, significantly improve material utilization, stable and durable, ensure maximum processing efficiency, large processing width, modular design, customized at will; optional bevel cutting head to achieve 45° internal bevel cutting, V-type, X-type, Y-type and other different types of bevels in one time, reduce the welding process and improve processing efficiency.
serial number Attributes KB-12035DGM KB-24035DGM KB-N*12035DGM 1 Processing format (length*width) 12000mm*3500mm 24000mm*3500mm N*12000mm*3500mm 2 X-axis travel 3500mm 3500mm 3500mm 3 Y-axis travel 12000mm 2*12000mm N*12000mm 4 Z axis travel 220mm 220mm 220mm 5 X/Y axis positioning accuracy ±0.05mm/m ±0.05mm/m ±0.05mm/m 6 X/Y axis repeat positioning accuracy ±0.05mm ±0.05mm ±0.05mm 7 XY maximum speed 80m/min 80m/min 80m/min 8 acceleration 0.8g 0.8g 0.8g 9 Power Specifications 3/380V/50HZ 3/380V/50HZ 3/380V/50HZ 10 Total power protection level IP54 IP54 IP54From the supplier
"Floor rail type bed design, significantly improve material utilization, stable and durable, ensure maximum processing efficiency, large processing width, modular design, customized at will; optional bevel cutting head to achieve 45° internal bevel cutting, V-type, X-type, Y-type and other different types of bevels in one time, reduce the welding process and improve processing efficiency.
serial number Attributes KB-12035DGM KB-24035DGM KB-N*12035DGM 1 Processing format (length*width) 12000mm*3500mm 24000mm*3500mm N*12000mm*3500mm 2 X-axis travel 3500mm 3500mm 3500mm 3 Y-axis travel 12000mm 2*12000mm N*12000mm 4 Z axis travel 220mm 220mm 220mm 5 X/Y axis positioning accuracy ±0.05mm/m ±0.05mm/m ±0.05mm/m 6 X/Y axis repeat positioning accuracy ±0.05mm ±0.05mm ±0.05mm 7 XY maximum speed 80m/min 80m/min 80m/min 8 acceleration 0.8g 0.8g 0.8g 9 Power Specifications 3/380V/50HZ 3/380V/50HZ 3/380V/50HZ 10 Total power protection level IP54 IP54 IP54About the supplier
