Machine tool
Price on request
The supplier hasn’t listed a price. We can get their current prices and MOQ.
Verify from $29 · written report in 3 business days · 100% refund if not satisfied
Price on request
The supplier hasn’t listed a price. We can get their current prices and MOQ.
Verify from $29 · written report in 3 business days · 100% refund if not satisfied
About this product
- Size: 2060x900x1640mm
- Color: Blue&White
- Setting mode: Table
- Controlling mode: Artificial
- Power source: Mechanical Drive
- Tool holder: Other
- Exports to: Mainland China, Africa, Southeast Asia, South Asia, Central Asia, USA and Canada, Russia, EU, Other European Countries, Hong Kong China, Macao China and Taiwan China, Others
- Made in: Jiangsu, China
About this product
- Size: 2060x900x1640mm
- Color: Blue&White
- Setting mode: Table
- Controlling mode: Artificial
- Power source: Mechanical Drive
- Tool holder: Other
- Exports to: Mainland China, Africa, Southeast Asia, South Asia, Central Asia, USA and Canada, Russia, EU, Other European Countries, Hong Kong China, Macao China and Taiwan China, Others
- Made in: Jiangsu, China
Product details
| Size | 2060x900x1640mm |
|---|---|
| Color | Blue&White |
| Setting mode | Table |
| Controlling mode | Artificial |
| Power source | Mechanical Drive |
| Tool holder | Other |
| Certification | CE |
| Guide rail | Horizontal Guide Rail |
| Processing accessory | Other |
Product details
| Size | 2060x900x1640mm |
|---|---|
| Color | Blue&White |
| Setting mode | Table |
| Controlling mode | Artificial |
| Power source | Mechanical Drive |
| Tool holder | Other |
| Certification | CE |
| Guide rail | Horizontal Guide Rail |
| Processing accessory | Other |
From the supplier
Modle
WL410E
Dsitance between centers
1000mm
Swing over bed
410mm
Swing over gap
255mm
Width of bed
250mm
Taper of spindle bore
MT6
Spindle nose
D1-6
Spindle bore
52mm
Number of spindle speeds
16
Range of spindle speeds
45-1800rpm
Range of cross feeds
0.0291-1.0190mm/r 17kinds
Range of longitudinal feeds
0.0506-1.7707mm/r 17kinds
Range of inch threads
Range of inch threads
Range of metric threads
0.2-14mm 39kinds
Range of diametrical pitches
8-44M.P 21kinds
Range of module pitcher
0.3-55M.P 18kinds
Top sllide travel
140mm
Cross slide travel
210mm
Taper of tailstock quill
MT3
Tailstcck quill travel
120mm
Tailstock quill diameter
50mm
Motor power
2.8KW
Packing size
2060x900x1640mm
Net weight
1550kg
WL410E
Dsitance between centers
1000mm
Swing over bed
410mm
Swing over gap
255mm
Width of bed
250mm
Taper of spindle bore
MT6
Spindle nose
D1-6
Spindle bore
52mm
Number of spindle speeds
16
Range of spindle speeds
45-1800rpm
Range of cross feeds
0.0291-1.0190mm/r 17kinds
Range of longitudinal feeds
0.0506-1.7707mm/r 17kinds
Range of inch threads
Range of inch threads
Range of metric threads
0.2-14mm 39kinds
Range of diametrical pitches
8-44M.P 21kinds
Range of module pitcher
0.3-55M.P 18kinds
Top sllide travel
140mm
Cross slide travel
210mm
Taper of tailstock quill
MT3
Tailstcck quill travel
120mm
Tailstock quill diameter
50mm
Motor power
2.8KW
Packing size
2060x900x1640mm
Net weight
1550kg
From the supplier
Modle
WL410E
Dsitance between centers
1000mm
Swing over bed
410mm
Swing over gap
255mm
Width of bed
250mm
Taper of spindle bore
MT6
Spindle nose
D1-6
Spindle bore
52mm
Number of spindle speeds
16
Range of spindle speeds
45-1800rpm
Range of cross feeds
0.0291-1.0190mm/r 17kinds
Range of longitudinal feeds
0.0506-1.7707mm/r 17kinds
Range of inch threads
Range of inch threads
Range of metric threads
0.2-14mm 39kinds
Range of diametrical pitches
8-44M.P 21kinds
Range of module pitcher
0.3-55M.P 18kinds
Top sllide travel
140mm
Cross slide travel
210mm
Taper of tailstock quill
MT3
Tailstcck quill travel
120mm
Tailstock quill diameter
50mm
Motor power
2.8KW
Packing size
2060x900x1640mm
Net weight
1550kg
WL410E
Dsitance between centers
1000mm
Swing over bed
410mm
Swing over gap
255mm
Width of bed
250mm
Taper of spindle bore
MT6
Spindle nose
D1-6
Spindle bore
52mm
Number of spindle speeds
16
Range of spindle speeds
45-1800rpm
Range of cross feeds
0.0291-1.0190mm/r 17kinds
Range of longitudinal feeds
0.0506-1.7707mm/r 17kinds
Range of inch threads
Range of inch threads
Range of metric threads
0.2-14mm 39kinds
Range of diametrical pitches
8-44M.P 21kinds
Range of module pitcher
0.3-55M.P 18kinds
Top sllide travel
140mm
Cross slide travel
210mm
Taper of tailstock quill
MT3
Tailstcck quill travel
120mm
Tailstock quill diameter
50mm
Motor power
2.8KW
Packing size
2060x900x1640mm
Net weight
1550kg
