Fully automatic drawstring garbage rolling bag making machine (overlap type & perforation type)
ZHEJIANG CHOVYTING MACHINERY CO.,LTD
The supplier hasn’t listed a price. We can get their current prices and MOQ.
Free quotes from independent agents · supplier checks approx. $5–$100 · 100% refund if not satisfied
Fully automatic drawstring garbage rolling bag making machine (overlap type & perforation type)
ZHEJIANG CHOVYTING MACHINERY CO.,LTDThe supplier hasn’t listed a price. We can get their current prices and MOQ.
Free quotes from independent agents · supplier checks approx. $5–$100 · 100% refund if not satisfied
About this product
- Materials: steel
- Size: 15000*2800*3000
- Color: red+white
- Exports to: Mainland China, Africa, Middle East, Southeast Asia, South Asia, Central Asia, USA and Canada, Latin America, Russia, EU, Other European Countries, Japan and South Korea, Others
- Made in: Zhejiang, China
About this product
- Materials: steel
- Size: 15000*2800*3000
- Color: red+white
- Exports to: Mainland China, Africa, Middle East, Southeast Asia, South Asia, Central Asia, USA and Canada, Latin America, Russia, EU, Other European Countries, Japan and South Korea, Others
- Made in: Zhejiang, China
Product details
| Materials | steel |
|---|---|
| Size | 15000*2800*3000 |
| Color | red+white |
Product details
| Materials | steel |
|---|---|
| Size | 15000*2800*3000 |
| Color | red+white |
From the supplier
Functions and Features:
This is a HIGH SPEED DRAW TAPE GARBAGE BAG MAKING MACHINE WITH BAG-ON-ROLL.
Hot Air Sealing Unit
The design on this unit seals the top with hot air. Continuous sealing increases productivity.
Fully Automatic Rewinding Machine for Overlap & Perforation Bag-on-roll without Core (Automatic Changing)
• Coreless winding of film rolls.
• Alarm system for auto stop.
• Automatic jam detection system.
• Automatic reset of film roll transfer.
Product Specifications:
MODEL
CW-1000PG+OR
CW-1000PG
Unwinder width
1000mm
1000mm
Unwinder diameter
φ900mm(max)
φ900mm(max)
Length of bag making
500-900mm
500-900mm
Bag making speed
100pcs/min
100pcs/min
Line speed
60m/min
60m/min
Rewinding width
300mm
300mm
Max diameter of rewinding
φ130mm
φ160mm
Finished roll exchange times
7 rolls/min
8 rolls/min
Film thickness
0.025-0.06mm
Total power
21KW
19KW
Machine dimension
15000*2800*3000mm
12500*2800*3000mm
Machine weight
4500kg
4100kg
Air compressor
7.5HP
Application Fields:
Drawstring and draw tape bags are preferred in many applications for their functionality and ease of use. The drawstring is pulled to tighten around the opening of the bag, helping to seal contents inside. Model CW-1000PG+OR can produce “Perforation on Roll” or “Inter-leave on Roll” depending on customers’ needs. It is an Easy-life style!
From the supplier
Functions and Features:
This is a HIGH SPEED DRAW TAPE GARBAGE BAG MAKING MACHINE WITH BAG-ON-ROLL.
Hot Air Sealing Unit
The design on this unit seals the top with hot air. Continuous sealing increases productivity.
Fully Automatic Rewinding Machine for Overlap & Perforation Bag-on-roll without Core (Automatic Changing)
• Coreless winding of film rolls.
• Alarm system for auto stop.
• Automatic jam detection system.
• Automatic reset of film roll transfer.
Product Specifications:
MODEL
CW-1000PG+OR
CW-1000PG
Unwinder width
1000mm
1000mm
Unwinder diameter
φ900mm(max)
φ900mm(max)
Length of bag making
500-900mm
500-900mm
Bag making speed
100pcs/min
100pcs/min
Line speed
60m/min
60m/min
Rewinding width
300mm
300mm
Max diameter of rewinding
φ130mm
φ160mm
Finished roll exchange times
7 rolls/min
8 rolls/min
Film thickness
0.025-0.06mm
Total power
21KW
19KW
Machine dimension
15000*2800*3000mm
12500*2800*3000mm
Machine weight
4500kg
4100kg
Air compressor
7.5HP
Application Fields:
Drawstring and draw tape bags are preferred in many applications for their functionality and ease of use. The drawstring is pulled to tighten around the opening of the bag, helping to seal contents inside. Model CW-1000PG+OR can produce “Perforation on Roll” or “Inter-leave on Roll” depending on customers’ needs. It is an Easy-life style!
