Electronic Scale Vertical Automatic Packaging Machine SUN-520
WENZHOU KINGPAK INTERNATIONAL CO.LTD
The supplier hasn’t listed a price. We can get their current prices and MOQ.
Verify from $29 · written report in 3 business days · 100% refund if not satisfied
Electronic Scale Vertical Automatic Packaging Machine SUN-520
WENZHOU KINGPAK INTERNATIONAL CO.LTDThe supplier hasn’t listed a price. We can get their current prices and MOQ.
Verify from $29 · written report in 3 business days · 100% refund if not satisfied
About this product
- Materials: Stainless Steel
- Size: 2300*1795*1650
- Color: Metal
- Exports to: Mainland China, Africa, Middle East, Southeast Asia, South Asia, Central Asia, USA and Canada, Latin America, Russia, EU, Other European Countries, Japan and South Korea, Hong Kong China, Macao China and Taiwan China, Others
- Made in: Zhejiang, China
About this product
- Materials: Stainless Steel
- Size: 2300*1795*1650
- Color: Metal
- Exports to: Mainland China, Africa, Middle East, Southeast Asia, South Asia, Central Asia, USA and Canada, Latin America, Russia, EU, Other European Countries, Japan and South Korea, Hong Kong China, Macao China and Taiwan China, Others
- Made in: Zhejiang, China
Product details
| Materials | Stainless Steel |
|---|---|
| Size | 2300*1795*1650 |
| Color | Metal |
Product details
| Materials | Stainless Steel |
|---|---|
| Size | 2300*1795*1650 |
| Color | Metal |
From the supplier
Application
Application for various of granule , strip , slice ,packing range within 1200ml.
Technical characteristics:
1. English and Chinese screen display ,operation is simple .
2. PLC computer system , function is more stable , adjustment any parameters not need stop machine.
3. It can stock ten dispose , simple to change variety.
4. Servo motor drawing film , position accurately.
5. Temperature independent control system ,precision get to±1℃.
6. Horizontal , vertical temperature control ,suitable for various of mix film , PE film,packing material, etc.
7. Packing type diversification , pillow sealing, standing type ,bags-connected punching etc.
8. Bag-making , sealing, packing, print date in one operation.
9. Work circumstance quiet, low noise.
Model
SUN-520
Bag length
80-400mm(L)
Bag width
80-250mm(W)
Max width of roll film
520mm
Packing speed
5-40bags/min
Measuring range
3000ml(Max)
Air consumption
0.65Mpa
Gas consumption
0.4m³/min
Power voltage
220VAC/50HZ
Power
4Kw
Dimension
(L)2300×(W)1795×(H)1650mm
Deadwight of machine
1200KG
Model
A14
Max. Cap.(g)
10-1500g
Weighing Accuracy(g)
0.1-1.5g
Max. Weighing Speed
110WPM
Hopper Volume
2500ml
Control Panel
10.4"LCD Keypad Screen/Touch Screen
Options
Dimple Plate/Timing Hopper/Printer/Rotary Top Cone
Driving System
Step Motor
Power Requirements
220V / 1500W / 50/60HZ / 10A
Packing Dimension(mm)
1700 (L)x1120 (W)x1100 (H)
Gross WGT
490KG
From the supplier
Application
Application for various of granule , strip , slice ,packing range within 1200ml.
Technical characteristics:
1. English and Chinese screen display ,operation is simple .
2. PLC computer system , function is more stable , adjustment any parameters not need stop machine.
3. It can stock ten dispose , simple to change variety.
4. Servo motor drawing film , position accurately.
5. Temperature independent control system ,precision get to±1℃.
6. Horizontal , vertical temperature control ,suitable for various of mix film , PE film,packing material, etc.
7. Packing type diversification , pillow sealing, standing type ,bags-connected punching etc.
8. Bag-making , sealing, packing, print date in one operation.
9. Work circumstance quiet, low noise.
Model
SUN-520
Bag length
80-400mm(L)
Bag width
80-250mm(W)
Max width of roll film
520mm
Packing speed
5-40bags/min
Measuring range
3000ml(Max)
Air consumption
0.65Mpa
Gas consumption
0.4m³/min
Power voltage
220VAC/50HZ
Power
4Kw
Dimension
(L)2300×(W)1795×(H)1650mm
Deadwight of machine
1200KG
Model
A14
Max. Cap.(g)
10-1500g
Weighing Accuracy(g)
0.1-1.5g
Max. Weighing Speed
110WPM
Hopper Volume
2500ml
Control Panel
10.4"LCD Keypad Screen/Touch Screen
Options
Dimple Plate/Timing Hopper/Printer/Rotary Top Cone
Driving System
Step Motor
Power Requirements
220V / 1500W / 50/60HZ / 10A
Packing Dimension(mm)
1700 (L)x1120 (W)x1100 (H)
Gross WGT
490KG
