About this product
- Materials: Aluminum, Steel, etc.
- Size: 815x520x720
- Color: Black, Blue
- Exports to: Mainland China, Africa, Middle East, Southeast Asia, South Asia, Central Asia, Latin America, Russia, EU
- Made in: Fujian, China
About this product
- Materials: Aluminum, Steel, etc.
- Size: 815x520x720
- Color: Black, Blue
- Exports to: Mainland China, Africa, Middle East, Southeast Asia, South Asia, Central Asia, Latin America, Russia, EU
- Made in: Fujian, China
Product details
| Materials | Aluminum, Steel, etc. |
|---|---|
| Size | 815x520x720 |
| Color | Black, Blue |
Product details
| Materials | Aluminum, Steel, etc. |
|---|---|
| Size | 815x520x720 |
| Color | Black, Blue |
From the supplier
HAILIN diesel water pumps are powered by reliabe, strong-built air cooled diesel engines. Ranging from clean water pumps, high pressure pumps, heavy-duty trash pumps, enonomic semi-trash pumps, chemical & sea water pumps. Suitable for various applications like dewatering, construction, pool water removal, irrigation, firefighting, civil engineering, etc. High quality pump housing and impeller extends the life of the pump. Self-priming design (Require initial priming to operate).
For more details, please refer to our website: www.hailinpower.com
Model
HL100SPL
Type
Self-priming (initial priming needed), centrifugal pump
Inlet
4" (100mm)
Outlet
4" (100mm)
Total Head
27 m
Discharge Volume
1300 L/min
Solid Handling
27 mm
Suction Head
6 m
Pump Body
Aluminium Alloy
Impeller
Cast Iron
Mechanical Seal
Silicon Carbide
Engine Type
Forced air cooled, 4-stroke diesel engine
Engine Model
HL188FV
Starting Method
HL100SPL: Recoil Start / HL100SPLE (electric start)
Displacement
474 cc
Rated Output
7.5kW (10.2hp) @3600rpm
Fuel Tank Capacity
12.5 Liters
Fuel Consumption Rate
335ml/kW.h @3600rpm
- Dry Weight
121 kg
- Dimension
815x520x780 mm
From the supplier
HAILIN diesel water pumps are powered by reliabe, strong-built air cooled diesel engines. Ranging from clean water pumps, high pressure pumps, heavy-duty trash pumps, enonomic semi-trash pumps, chemical & sea water pumps. Suitable for various applications like dewatering, construction, pool water removal, irrigation, firefighting, civil engineering, etc. High quality pump housing and impeller extends the life of the pump. Self-priming design (Require initial priming to operate).
For more details, please refer to our website: www.hailinpower.com
Model
HL100SPL
Type
Self-priming (initial priming needed), centrifugal pump
Inlet
4" (100mm)
Outlet
4" (100mm)
Total Head
27 m
Discharge Volume
1300 L/min
Solid Handling
27 mm
Suction Head
6 m
Pump Body
Aluminium Alloy
Impeller
Cast Iron
Mechanical Seal
Silicon Carbide
Engine Type
Forced air cooled, 4-stroke diesel engine
Engine Model
HL188FV
Starting Method
HL100SPL: Recoil Start / HL100SPLE (electric start)
Displacement
474 cc
Rated Output
7.5kW (10.2hp) @3600rpm
Fuel Tank Capacity
12.5 Liters
Fuel Consumption Rate
335ml/kW.h @3600rpm
- Dry Weight
121 kg
- Dimension
815x520x780 mm
