Cat7 Sftp Cu Double Shielded Lan Cable
Guangzhou GHT Wire&Cable Co., Ltd.
The supplier hasn’t listed a price. We can get their current prices and MOQ.
Verify from $29 · written report in 3 business days · 100% refund if not satisfied
Cat7 Sftp Cu Double Shielded Lan Cable
Guangzhou GHT Wire&Cable Co., Ltd.The supplier hasn’t listed a price. We can get their current prices and MOQ.
Verify from $29 · written report in 3 business days · 100% refund if not satisfied
About this product
- Size: 0.56mm, 0.58mm, Per Customer Request
- Exports to: Mainland China, Africa, Middle East, Southeast Asia, South Asia, Central Asia, USA and Canada, Latin America, Russia, EU, Other European Countries, Japan and South Korea, Hong Kong China, Macao China and Taiwan China, Others
- Made in: Guangdong, China
About this product
- Size: 0.56mm, 0.58mm, Per Customer Request
- Exports to: Mainland China, Africa, Middle East, Southeast Asia, South Asia, Central Asia, USA and Canada, Latin America, Russia, EU, Other European Countries, Japan and South Korea, Hong Kong China, Macao China and Taiwan China, Others
- Made in: Guangdong, China
Product details
| Size | 0.56mm, 0.58mm, Per Customer Request |
|---|
Product details
| Size | 0.56mm, 0.58mm, Per Customer Request |
|---|
From the supplier
- Specification:
- 1. Conductor use pure copper(99.99%)-low resistance, signals attenuation, fast speed, high transmission rate and so on;
- 2. Insulation material used HDPE(high density polyethylene), product by the high communication degree wiredrawing and annealing in-line machine;
- 3. Shielded material adopt conductive aluminum foil, prevent signals attenuation decrease and the disturbing from the outer signals.
This product is widely apply to variety of network cabling and transmission media, such as audio, digital communication, images, video and other high-speed, large-capacity and security, high privacy at local area network environment.
Product prameter:
Model
4pairs twisted 1000ft BC SFTP Lan Cable Cat7 Network Cable
Conductor Size
22AWG, 23AWG, 24AWG
Stranded 7x0.12mm/7x0.16mm/7x0.20mm
Conductor Material
BC/CCU/CCA/OFC/CCS
Number Of Conductor
2P, 4P, 8P, 10P, 25P,32P, 50P, 100P, 200P
Shielded
UTP/FTP/STP/SFTP /SSTP
Flammability Grade:
CMX,CM,MP,CMG,MPG,CMR
Indoor / Outdoor
Single jacket / Double jacket
Insulation Material
PE , HDPE
Insulation Thickness
0.55mm
Number of pairs: 4 pairs
Pair1: Orange/White Orange
Pair2: Blue/ White Blue
Pair3: Green/ White Green
Pair4: Brown/White Brown
Jacket Material
PVC, ROHS PVC, LSZH PVC
Jacket Thickness
0.92-0.95mm
DC Resistance(Max.)
9.5Ω/100m
DC Resistance Imbalance
2.50%
Working Capacitance(Max.)
5.4nF/100m
Insulation Resistance
10000MΩ.km
Transmission Velocity
65%
Operating Temperature
-20 °C - +75 °C
PVC Jacket Color
As client’s request.
FAQ
1, What’s the MOQ?
30000Meters. 100M/305M/500M/Roll.
2, How to get the samples?
We have most of the commonly used samples in Stock.
We can offer the free samples immediately.
3, What’s the payment terms?
TT, LC, DP, Western Union and Paypal etc are available.
4, What’s the delivery date?
Most of the commonly used products are in Stock. We are a manufacturer with two factories. We can arrange it within 3-5 days.
Also the delivery date as your requirement while the Bulk Production.
From the supplier
- Specification:
- 1. Conductor use pure copper(99.99%)-low resistance, signals attenuation, fast speed, high transmission rate and so on;
- 2. Insulation material used HDPE(high density polyethylene), product by the high communication degree wiredrawing and annealing in-line machine;
- 3. Shielded material adopt conductive aluminum foil, prevent signals attenuation decrease and the disturbing from the outer signals.
This product is widely apply to variety of network cabling and transmission media, such as audio, digital communication, images, video and other high-speed, large-capacity and security, high privacy at local area network environment.
Product prameter:
Model
4pairs twisted 1000ft BC SFTP Lan Cable Cat7 Network Cable
Conductor Size
22AWG, 23AWG, 24AWG
Stranded 7x0.12mm/7x0.16mm/7x0.20mm
Conductor Material
BC/CCU/CCA/OFC/CCS
Number Of Conductor
2P, 4P, 8P, 10P, 25P,32P, 50P, 100P, 200P
Shielded
UTP/FTP/STP/SFTP /SSTP
Flammability Grade:
CMX,CM,MP,CMG,MPG,CMR
Indoor / Outdoor
Single jacket / Double jacket
Insulation Material
PE , HDPE
Insulation Thickness
0.55mm
Number of pairs: 4 pairs
Pair1: Orange/White Orange
Pair2: Blue/ White Blue
Pair3: Green/ White Green
Pair4: Brown/White Brown
Jacket Material
PVC, ROHS PVC, LSZH PVC
Jacket Thickness
0.92-0.95mm
DC Resistance(Max.)
9.5Ω/100m
DC Resistance Imbalance
2.50%
Working Capacitance(Max.)
5.4nF/100m
Insulation Resistance
10000MΩ.km
Transmission Velocity
65%
Operating Temperature
-20 °C - +75 °C
PVC Jacket Color
As client’s request.
FAQ
1, What’s the MOQ?
30000Meters. 100M/305M/500M/Roll.
2, How to get the samples?
We have most of the commonly used samples in Stock.
We can offer the free samples immediately.
3, What’s the payment terms?
TT, LC, DP, Western Union and Paypal etc are available.
4, What’s the delivery date?
Most of the commonly used products are in Stock. We are a manufacturer with two factories. We can arrange it within 3-5 days.
Also the delivery date as your requirement while the Bulk Production.
