Specification:

Weight: Tare Weight 13T Loading capacity 60 T Total weight 63 T Dimensions: Dimension 13000×2500*3800mm (The final dimensions depend on the final design drawings) Tanker capacity 56m3 (56000L) Tanker body: Design/welding technology Heavy duty and extra durability designed;welding by automatic Submerged-Arc processes. Tanker body The tanker body made of 5mm, tanker ends made of 6mm thickness steel, Q235 steel Bottom chassis High strength Q345B steel Tanker shape “V” shape Silo 1 silo Manhole: 3 pieces, (Diameter is 500mm) Discharge mouth 4 inch Discharge mouth Safety pressure valve Standard Discharge hose 8m with Hose carries, the length is according to customer requirement Air compressor 12m3 double-cylinder air compressor, Bohai brand Engine Diesel Engine,Weichai 4102 engine Rear ladder and handrail Standard Retention volume <0.3% OEM parts: 　　　　 Axle 3* 13 tons capacity, FUWA brand (Chinese best brand) King Pin 2.00 /3.5 inch, bolting king pin, JOST brand Suspension Heavy duty suspension with equalizers, American design (high-strength type) Steel Spring Six sets of 10pcs leaf spring, 16mm thickness, 90mm width Landing legs JOST brand, manual operation landing legs with sand shoe Tire specs 12R22.5, or 315/80R22.5 double coin brand Rim 9.0-22.5 Number of wheel 13 pieces(including one spare wheel) Brake system WABCO relay valve; Four double and two single brake chamber; One unit of reliable local brand 45L air tank; Two units of reliable local brand standard coppery air-connector.　 ABS system Without（Can be choose freely,450 USD/set） Electrical: One unit of 24V 7-pin ISO 1185 socket; LED light (standard rear light, turn light, rear reflector, side light, side reflector etc.) 　　　Miscellaneous: Painting color advised by client Marking Standard Side Guard Standard spare wheel carrier Two set of heavy duty spare wheel carriers, including a riser. Tools box One piece (1. 0*0. 5*0. 5m)(equipped with 1 Tire spanner,1 gudgeon sleeve and 1 cranking bar) Note: All the details not mentioned will design as the final confirmation with the customer
