Bitumen Mixture Automatic Air Pressure Wheel Rut Forming Machine
Zhejiang Chenxin Machine Equipments Co., Ltd
The supplier hasn’t listed a price. We can get their current prices and MOQ.
Verify from $29 · written report in 3 business days · 100% refund if not satisfied
Bitumen Mixture Automatic Air Pressure Wheel Rut Forming Machine
Zhejiang Chenxin Machine Equipments Co., LtdThe supplier hasn’t listed a price. We can get their current prices and MOQ.
Verify from $29 · written report in 3 business days · 100% refund if not satisfied
About this product
- Size: 2000*630*1360mm
- Exports to: Mainland China, Africa, Middle East, Southeast Asia, South Asia, Central Asia, USA and Canada, Latin America, Russia, EU, Other European Countries, Hong Kong China, Macao China and Taiwan China, Others
- Made in: Zhejiang, China
About this product
- Size: 2000*630*1360mm
- Exports to: Mainland China, Africa, Middle East, Southeast Asia, South Asia, Central Asia, USA and Canada, Latin America, Russia, EU, Other European Countries, Hong Kong China, Macao China and Taiwan China, Others
- Made in: Zhejiang, China
Product details
| Size | 2000*630*1360mm |
|---|
Product details
| Size | 2000*630*1360mm |
|---|
From the supplier
Application:
This product is manufactured according to the JTGE20-2011 of T0703-2011, uses advanced single chip control technology, sensor technology, electronic display technology, pneumatic and mechanical machining technology. It can be used for highway and urban road, airport runway asphalt mixture specimen molding in engineering, physical and mechanical properties test for asphalt mixture.
Model
CXIS-III
Radius of roller
500mm width: 300mm
Temp. range of roller
Room temp. to 200℃, (set optionally)
Loading truck speed
6 times of round-trip /min.
Loading truck running distance
300mm
Times of the truck running
0-999 times (set optionally)
Roller line pressure
9KN
Specimen size
300*300*50mm
Dimension
200*63*136cm
Weight
400KG
Power supply
380V±5%，50HZ
Power
3KW
From the supplier
Application:
This product is manufactured according to the JTGE20-2011 of T0703-2011, uses advanced single chip control technology, sensor technology, electronic display technology, pneumatic and mechanical machining technology. It can be used for highway and urban road, airport runway asphalt mixture specimen molding in engineering, physical and mechanical properties test for asphalt mixture.
Model
CXIS-III
Radius of roller
500mm width: 300mm
Temp. range of roller
Room temp. to 200℃, (set optionally)
Loading truck speed
6 times of round-trip /min.
Loading truck running distance
300mm
Times of the truck running
0-999 times (set optionally)
Roller line pressure
9KN
Specimen size
300*300*50mm
Dimension
200*63*136cm
Weight
400KG
Power supply
380V±5%，50HZ
Power
3KW
About the supplier
- ✓Exhibited at 10 of the last 10 Canton Fairs
- ✓Industry and Trade Company
- ✓Founded 2002
- ✓Canton Fair Premium Supplier
- ✓National high-tech enterprise
Manufacturing exhibitors show in Phase 1 of the Canton Fair, 15 to 19 October 2026.
- Exhibited at 10 of the last 10 Canton Fairs
- Industry and Trade Company
- Founded 2002
- Canton Fair Premium Supplier
