About this product
- Materials: Shaft: SS304 welding shaft
- Size: 233*190*226
- Color: blue
- Exports to: Africa, Middle East, Southeast Asia, South Asia, Central Asia, Latin America, Russia, EU
- Made in: Fujian, China
About this product
- Materials: Shaft: SS304 welding shaft
- Size: 233*190*226
- Color: blue
- Exports to: Africa, Middle East, Southeast Asia, South Asia, Central Asia, Latin America, Russia, EU
- Made in: Fujian, China
Product details
| Materials | Shaft: SS304 welding shaft |
|---|---|
| Size | 233*190*226 |
| Color | blue |
From the supplier
WORKING PRINCIPLE
Volumetric water pumps are capable of developing high discharge heads at low flow rates. The fluid in a Volumetric pump is pumped into a Volumetric channel (around the edge of the casing). Unlike standard centrifugal pumps, the curves do not flatten as the fluid flow decreases. To summarise the fluid moves along the circumference for the inlet to the outlet of the casing with increasing pressure.APPLICATIONS
-Suitable for use with clean water, or non-aggressive liquids only, without sand or other solid impurities.
-Suitable for small living water supply, automatic water sprinkler system, small air conditioner system or supporting equipment etc. ADVANTAGE
3-second time delay of pump start after plugging into the socket to avoid potential danger caused by electric sparks
Automatic stop in 6 minutes in case of no water inside
Automatic switching to small flow control system in condition of small water flow
Automatic 10-second operation every 48 hours for anti-block protection in case of no use for long time
OPERATING LIMITS
-IEC60034-1
-IEC335-1
-IEC34-1
-ISO2548
SPECIAL FEATURES ON REQUESTAnti-rust treatment for casting
No block system
AISI 1045 motor shaft
Carbon/SiC/V mechanical seal
Other voltage and frequnecy
Insultation class: FSPECIAL FEATURES ON REQUEST
Anti-rust treatment for casting
No block system
AISI 1045 motor shaft
Carbon/SiC/V mechanical seal
Other voltage and frequnecy
Insultation class: F
Pump body/motor bracket: cast iron
Impeller: Brass
Cast Iron flange for 0.2kW-0.75kW
Galavanized flange for 1.1kW-1.5kW
Bearing: C&U
100% copper winding
Built-in thermal protector for single phase motor
Motor shaft: AISI 304 welded shaft
Mechanical seal: Graphite/Ceramic/NBR/SUS304
FEATUREOPERATING LIMITS
Total suction lift up to 6-8 mt. with foot valve
Max. operating pressure: 8 bar.
Max. ambient temperature: +40℃
Max. liquid temperature: +90℃
Max. altitude: +1000 mt.
MOTORS
100% copper winding
Insultation class: B
Protection: IP44
Speed of rotation: 2850rpm
Continuous duty: S1
