About this product
- Materials: cast iron, copper, aluminum
- Size: 285*155*195
- Color: Blue
- Exports to: Mainland China, Africa, Middle East, Southeast Asia, South Asia, Central Asia, Latin America, Russia, Other European Countries, Others
- Made in: Fujian, China
About this product
- Materials: cast iron, copper, aluminum
- Size: 285*155*195
- Color: Blue
- Exports to: Mainland China, Africa, Middle East, Southeast Asia, South Asia, Central Asia, Latin America, Russia, Other European Countries, Others
- Made in: Fujian, China
Product details
| Materials | cast iron, copper, aluminum |
|---|---|
| Size | 285*155*195 |
| Color | Blue |
Product details
| Materials | cast iron, copper, aluminum |
|---|---|
| Size | 285*155*195 |
| Color | Blue |
From the supplier
Application
Suitable for use with clean water, or non-aggressive liquids only, without sand or other solid impurities
Suitable for industrial use and urban water supply, pressure boosting for high buildings and fire fighting, garden imgation, long-distance water transfer,
heating wentilation and air controlling, circulation and pressure boosting for cold hot water, and supporting equipment etc.
Pump
Pump body: cast iron
Impeller: 0.75-5.5kW with brass， 11-15kW with Cast Iron impress
Motor shaft: AISI1045 or Stainless steel welding shaft
Mechanical seal: NBR/Graphite/Ceramic
Motor
High efficiency bearing
100% copper wire
Single phase power supply with capacitor permanently activvated
Insulation: B
Protection: IP44
Operating Limits
Suntion lift up to 6-8m with foot valve
Maximum operating pressure: 8bar
Maximum ambient temperature: +40℃
Liquid temperature up to +90℃
Maximum altitude +1000m
From the supplier
Application
Suitable for use with clean water, or non-aggressive liquids only, without sand or other solid impurities
Suitable for industrial use and urban water supply, pressure boosting for high buildings and fire fighting, garden imgation, long-distance water transfer,
heating wentilation and air controlling, circulation and pressure boosting for cold hot water, and supporting equipment etc.
Pump
Pump body: cast iron
Impeller: 0.75-5.5kW with brass， 11-15kW with Cast Iron impress
Motor shaft: AISI1045 or Stainless steel welding shaft
Mechanical seal: NBR/Graphite/Ceramic
Motor
High efficiency bearing
100% copper wire
Single phase power supply with capacitor permanently activvated
Insulation: B
Protection: IP44
Operating Limits
Suntion lift up to 6-8m with foot valve
Maximum operating pressure: 8bar
Maximum ambient temperature: +40℃
Liquid temperature up to +90℃
Maximum altitude +1000m
