About this product
- Materials: SUS304
- Size: 6000X2200X2300MM
- Color: metal color
- Exports to: Mainland China, Africa, Middle East, Southeast Asia, South Asia, USA and Canada, Latin America, Russia, EU, Other European Countries, Others
- Made in: Jiangsu, China
About this product
- Materials: SUS304
- Size: 6000X2200X2300MM
- Color: metal color
- Exports to: Mainland China, Africa, Middle East, Southeast Asia, South Asia, USA and Canada, Latin America, Russia, EU, Other European Countries, Others
- Made in: Jiangsu, China
Product details
| Materials | SUS304 |
|---|---|
| Size | 6000X2200X2300MM |
| Color | metal color |
Product details
| Materials | SUS304 |
|---|---|
| Size | 6000X2200X2300MM |
| Color | metal color |
From the supplier
Description
(1) This filling line specially produces 3&5 gallons barreled drinking water.
(2)This series barreled filling production line integrates bottle washer, filler and sealer into one unit.
(3) In order to achieve the purpose of washing and sterilizing, bottle washer adopts multiple liquid injections washing and disinfectant spray, and washing solution can be used circularly. The sealer can seal bottle caps automatically.
(4) This filling line equips with water spraying device to sterilize caps of bottles in order to ensure those caps are aseptic and healthy.
(5) This line also can automatically carry out bottle washing, sterilizing, filling, capping, counting and products discharging.
(6) It has features of complete functional, novel design, and high degree of automation. It is a new kind of barreled water auto-producing line, which integrates mechanism, electricity and pneumatics technologies together.
Main Technical Parameter
Model
QGF-100
QGF-300
QGF-450
QGF-600
QGF-900
QGF-1200
QGF-2000
Filling heads
1
2
3
4
8
12
16
Volume(L)
18.9
18.9
18.9
18.9
18.9
18.9
18.9
Barrel size(mm)
φ270×490
φ270×490
φ270×490
φ270×490
φ270×490
φ270×490
φ270×490
Capacity(B/n)
100-120
200-240
300-400
600
900
1200
2000
Gas pressure(mpa)
0.4-0.6
0.4-0.6
0.6
0.6
0.6
0.6
0.6
Gas consumption (m3/min)
0.37
0.6
0.6
1.2
2.2
3
4.5
Motor power(Kw)
1.75
3.22
4.8
8.5
8.5
8.5
8.5
5 Gallon Water Filling Machine
Related Products
Water treatment system
(please kindly supply us the raw water analysis report)
Raw water tank ----- Sand Filter ---- -Carbon Filter --- Precision Filter ---- R/O ----- UV sterilizer----Ozone Generator------Pure water Tank ----Filling Machine
Automatic Shrink Label Machine ( For bottle cap )
include shrink tunnel and steam generator,we have semi-automatc type for choose.Semi-automatic Gallon Bottle Blow Moulding Machine
This type PET blow moulding machine for large PET bottles is specially designed to produce 5-gallon PET container. Its max output is up to 90 BPH for 5-gallon bottle and even could reach 120 bottles per hour for the one way used thin wall 5 gallon bottles.
From the supplier
Description
(1) This filling line specially produces 3&5 gallons barreled drinking water.
(2)This series barreled filling production line integrates bottle washer, filler and sealer into one unit.
(3) In order to achieve the purpose of washing and sterilizing, bottle washer adopts multiple liquid injections washing and disinfectant spray, and washing solution can be used circularly. The sealer can seal bottle caps automatically.
(4) This filling line equips with water spraying device to sterilize caps of bottles in order to ensure those caps are aseptic and healthy.
(5) This line also can automatically carry out bottle washing, sterilizing, filling, capping, counting and products discharging.
(6) It has features of complete functional, novel design, and high degree of automation. It is a new kind of barreled water auto-producing line, which integrates mechanism, electricity and pneumatics technologies together.
Main Technical Parameter
Model
QGF-100
QGF-300
QGF-450
QGF-600
QGF-900
QGF-1200
QGF-2000
Filling heads
1
2
3
4
8
12
16
Volume(L)
18.9
18.9
18.9
18.9
18.9
18.9
18.9
Barrel size(mm)
φ270×490
φ270×490
φ270×490
φ270×490
φ270×490
φ270×490
φ270×490
Capacity(B/n)
100-120
200-240
300-400
600
900
1200
2000
Gas pressure(mpa)
0.4-0.6
0.4-0.6
0.6
0.6
0.6
0.6
0.6
Gas consumption (m3/min)
0.37
0.6
0.6
1.2
2.2
3
4.5
Motor power(Kw)
1.75
3.22
4.8
8.5
8.5
8.5
8.5
5 Gallon Water Filling Machine
Related Products
Water treatment system
(please kindly supply us the raw water analysis report)
Raw water tank ----- Sand Filter ---- -Carbon Filter --- Precision Filter ---- R/O ----- UV sterilizer----Ozone Generator------Pure water Tank ----Filling Machine
Automatic Shrink Label Machine ( For bottle cap )
include shrink tunnel and steam generator,we have semi-automatc type for choose.Semi-automatic Gallon Bottle Blow Moulding Machine
This type PET blow moulding machine for large PET bottles is specially designed to produce 5-gallon PET container. Its max output is up to 90 BPH for 5-gallon bottle and even could reach 120 bottles per hour for the one way used thin wall 5 gallon bottles.
