170f/X170f Diesel Engine
JINTAN DIESEL ENGINE CHANGZHOU CO.,LTD.
The supplier hasn’t listed a price. We can get their current prices and MOQ.
Free quotes from independent agents · supplier checks approx. $5–$100 · 100% refund if not satisfied
170f/X170f Diesel Engine
JINTAN DIESEL ENGINE CHANGZHOU CO.,LTD.The supplier hasn’t listed a price. We can get their current prices and MOQ.
Free quotes from independent agents · supplier checks approx. $5–$100 · 100% refund if not satisfied
About this product
- Size: 540x380x410
- Exports to: Mainland China, Africa, Middle East, Southeast Asia, South Asia, Central Asia, Latin America
About this product
- Size: 540x380x410
- Exports to: Mainland China, Africa, Middle East, Southeast Asia, South Asia, Central Asia, Latin America
Product details
| Size | 540x380x410 |
|---|
Product details
| Size | 540x380x410 |
|---|
From the supplier
Model
Model
170F
X170F
Type
Type
Single Cylinder, Four-Stroke
Single-cylinder Four-stroke
Combustion Method
Combustion system
Vortex Chamber Type
Swirlcombustion Chamber
Cylinder Diameter x Stroke (mm）
Borexstroke(mm)
70×75
70×75
Compression Ratio
Compression ratio
20±1
20±1
1Hourly Power kW/r/min
1-hour rated output(kw/r/min)
3.23/2600
4.05/3000
12Hourly PowerkW/r/min
12-hour rated output(kw/r/min)
2.94/2600
3.68/3000
Fuel Consumption Rate
Specific fuel consumption(g/kw h)
≤289.7
≤293.8
Oil Consumption Rate
Specific lube oil consumption(g/kw h)
≤4.76
≤4.76
Cooling Method
Cooling system
Forced Air Cooling
Forced air cooled
Lubrication Method
Lubrication system
Splash Lubrication
Splashing
Starting Method
Starting method
Hand Crank Speed Start
Hand crank
Net Weight (kg)
Net weight(kg)
41
43
Power Output Type
Method of power output
Flywheel End Output
Output of flywheel end
External Dimensions（mm）
Overall dimensions(mm)
540×380×410
540×380×410
From the supplier
Model
Model
170F
X170F
Type
Type
Single Cylinder, Four-Stroke
Single-cylinder Four-stroke
Combustion Method
Combustion system
Vortex Chamber Type
Swirlcombustion Chamber
Cylinder Diameter x Stroke (mm）
Borexstroke(mm)
70×75
70×75
Compression Ratio
Compression ratio
20±1
20±1
1Hourly Power kW/r/min
1-hour rated output(kw/r/min)
3.23/2600
4.05/3000
12Hourly PowerkW/r/min
12-hour rated output(kw/r/min)
2.94/2600
3.68/3000
Fuel Consumption Rate
Specific fuel consumption(g/kw h)
≤289.7
≤293.8
Oil Consumption Rate
Specific lube oil consumption(g/kw h)
≤4.76
≤4.76
Cooling Method
Cooling system
Forced Air Cooling
Forced air cooled
Lubrication Method
Lubrication system
Splash Lubrication
Splashing
Starting Method
Starting method
Hand Crank Speed Start
Hand crank
Net Weight (kg)
Net weight(kg)
41
43
Power Output Type
Method of power output
Flywheel End Output
Output of flywheel end
External Dimensions（mm）
Overall dimensions(mm)
540×380×410
540×380×410
