Electric equipment
0.6/1kV copper core XLPE insulated PVC sheathed 4-core low voltage power cable,
Huake Zhonglan Cable Co., Ltd.1/10 fairsIndustry and Trade Company
Price on request
The supplier hasn’t listed a price. We can get their current prices and MOQ.
Verify from $29 · written report in 3 business days · 100% refund if not satisfied
0.6/1kV copper core XLPE insulated PVC sheathed 4-core low voltage power cable,
Huake Zhonglan Cable Co., Ltd.1/10 fairsIndustry and Trade Company
Price on request
The supplier hasn’t listed a price. We can get their current prices and MOQ.
Verify from $29 · written report in 3 business days · 100% refund if not satisfied
About this product
- Size: 3*2.5+1*1.5
- Color: black
- Application: Other
- Certification: ISO9001Other
- Insulation material: XLPE
- Sheath material: PVC
- Exports to: Mainland China, Africa, Middle East, Southeast Asia, South Asia, Central Asia, USA and Canada, Latin America, Russia, EU, Other European Countries, Hong Kong China, Macao China and Taiwan China, Others
- Made in: Shannxi, China
About this product
- Size: 3*2.5+1*1.5
- Color: black
- Application: Other
- Certification: ISO9001Other
- Insulation material: XLPE
- Sheath material: PVC
- Exports to: Mainland China, Africa, Middle East, Southeast Asia, South Asia, Central Asia, USA and Canada, Latin America, Russia, EU, Other European Countries, Hong Kong China, Macao China and Taiwan China, Others
- Made in: Shannxi, China
Product details
| Size | 3*2.5+1*1.5 |
|---|---|
| Color | black |
| Application | Other |
| Certification | ISO9001Other |
| Insulation material | XLPE |
| Sheath material | PVC |
| Conductor type | Other |
| Conductor material | Other |
| Material shape | Other |
| Rangeof application | Other |
| Brand | Other |
Product details
| Size | 3*2.5+1*1.5 |
|---|---|
| Color | black |
| Application | Other |
| Certification | ISO9001Other |
| Insulation material | XLPE |
| Sheath material | PVC |
| Conductor type | Other |
| Conductor material | Other |
| Material shape | Other |
| Rangeof application | Other |
| Brand | Other |
From the supplier
YJV 3×2.5+1×1.5 is a 0.6/1kV copper core XLPE insulated PVC sheathed 4-core low voltage power cable, manufactured in accordance with GB/T 12706.1 standard. It adopts high-purity stranded oxygen-free copper conductor, including 3 main cores with 2.5mm² cross-sectional area and 1 auxiliary core with 1.5mm² cross-sectional area. The insulation layer is XLPE, with a long-term operating temperature of 90℃ and a maximum short-circuit temperature of 250℃. The outer PVC sheath is wear-resistant, moisture-proof, aging-resistant and highly protective, suitable for various indoor laying environments.
This cable is specially designed for three-phase four-wire power supply. The 3 cores of 2.5mm² are used as phase wires (yellow/green/red), and the 1 core of 1.5mm² is used as neutral wire (blue). The core specification matching is reasonable, and the current carrying capacity is suitable for light and medium-sized power equipment. It is widely used in household lighting power distribution, small electromechanical equipment power supply, building weak current wiring, store power distribution, indoor conduit embedding and other scenarios. The cable has good flexibility, convenient wiring and stable insulation performance, which can meet the safe use needs of daily low-voltage power distribution.
From the supplier
YJV 3×2.5+1×1.5 is a 0.6/1kV copper core XLPE insulated PVC sheathed 4-core low voltage power cable, manufactured in accordance with GB/T 12706.1 standard. It adopts high-purity stranded oxygen-free copper conductor, including 3 main cores with 2.5mm² cross-sectional area and 1 auxiliary core with 1.5mm² cross-sectional area. The insulation layer is XLPE, with a long-term operating temperature of 90℃ and a maximum short-circuit temperature of 250℃. The outer PVC sheath is wear-resistant, moisture-proof, aging-resistant and highly protective, suitable for various indoor laying environments.
This cable is specially designed for three-phase four-wire power supply. The 3 cores of 2.5mm² are used as phase wires (yellow/green/red), and the 1 core of 1.5mm² is used as neutral wire (blue). The core specification matching is reasonable, and the current carrying capacity is suitable for light and medium-sized power equipment. It is widely used in household lighting power distribution, small electromechanical equipment power supply, building weak current wiring, store power distribution, indoor conduit embedding and other scenarios. The cable has good flexibility, convenient wiring and stable insulation performance, which can meet the safe use needs of daily low-voltage power distribution.
