ZhIicheng Door Control-Floor spring ZC208
ZHAOQING CITY ZHISHENG DOOR CONTROL CO.,LTD.
The supplier hasn’t listed a price. We can get their current prices and MOQ.
Verify from $29 · written report in 3 business days · 100% refund if unreachable
ZhIicheng Door Control-Floor spring ZC208
ZHAOQING CITY ZHISHENG DOOR CONTROL CO.,LTD.The supplier hasn’t listed a price. We can get their current prices and MOQ.
Verify from $29 · written report in 3 business days · 100% refund if unreachable
About this product
- Size: L275 X W108 X H40.5
- Color: Sliver
- Exports to: Mainland China, Southeast Asia, South Asia, Russia, Other European Countries, Hong Kong China, Macao China and Taiwan China, Others
- Made in: Guangdong, China
About this product
- Size: L275 X W108 X H40.5
- Color: Sliver
- Exports to: Mainland China, Southeast Asia, South Asia, Russia, Other European Countries, Hong Kong China, Macao China and Taiwan China, Others
- Made in: Guangdong, China
Product details
| Size | L275 X W108 X H40.5 |
|---|---|
| Color | Sliver |
Product details
| Size | L275 X W108 X H40.5 |
|---|---|
| Color | Sliver |
From the supplier
ZC 208
POWER
EN-2
EN-3
MAXIMUM DOOR WIDTH
850 mm
950 mm
MAXIMUM DOOR WEIGHT
80 Kg
100 Kg
MAXIMUM OPENING ANGLE
120°
SPEED CONTROL 1
90° TO 25°
SPEED CONTROL 2
25° TO 0°
HOLD OPEN
105° - 90°
FLOOR SPRING WEIGHT
4.50 Kg
4.55 Kg
Length
275 mm
275 mm
DIMENSIONS Width
108 mm
108 mm
Height
40.5 mm
40.5 mm
TESTED
500.000 Cycles
SPECIFICATIONS
- · Dual valves speed adjustment.
Speed 1 from 90° to 25°
Speed 2 from 25° to 0°
- · Maximum opening angle : 120°
- · Easy installation :
Standard cement box dimensions.
Suitable for left and right hand opening doors.
- · Once sealed in the cement, the position of the floor spring can be adjusted:
5 mm left to right.
6 mm on the length.
4 mm in height.
Please contract us with:jay@gdzhicheng.com/+8618319399110
wechat number:18319399110
From the supplier
ZC 208
POWER
EN-2
EN-3
MAXIMUM DOOR WIDTH
850 mm
950 mm
MAXIMUM DOOR WEIGHT
80 Kg
100 Kg
MAXIMUM OPENING ANGLE
120°
SPEED CONTROL 1
90° TO 25°
SPEED CONTROL 2
25° TO 0°
HOLD OPEN
105° - 90°
FLOOR SPRING WEIGHT
4.50 Kg
4.55 Kg
Length
275 mm
275 mm
DIMENSIONS Width
108 mm
108 mm
Height
40.5 mm
40.5 mm
TESTED
500.000 Cycles
SPECIFICATIONS
- · Dual valves speed adjustment.
Speed 1 from 90° to 25°
Speed 2 from 25° to 0°
- · Maximum opening angle : 120°
- · Easy installation :
Standard cement box dimensions.
Suitable for left and right hand opening doors.
- · Once sealed in the cement, the position of the floor spring can be adjusted:
5 mm left to right.
6 mm on the length.
4 mm in height.
Please contract us with:jay@gdzhicheng.com/+8618319399110
wechat number:18319399110
