YZYX140CJGX Screw Oil Press Machine
Mian Yang Guang Xin Import & Export Co.,Ltd
The supplier hasn’t listed a price. We can get their current prices and MOQ.
Verify from $29 · written report in 3 business days · 100% refund if unreachable
YZYX140CJGX Screw Oil Press Machine
Mian Yang Guang Xin Import & Export Co.,LtdThe supplier hasn’t listed a price. We can get their current prices and MOQ.
Verify from $29 · written report in 3 business days · 100% refund if unreachable
About this product
- Materials: stainless steel,carbon steel,iron
- Size: L2300*W820*H1420
- Color: Yellow
- Exports to: Mainland China, Africa, Middle East, Southeast Asia, South Asia, Central Asia, USA and Canada, Latin America, Russia, Other European Countries, Japan and South Korea, Hong Kong China, Macao China and Taiwan China, Others
- Made in: Sichuan, China
About this product
- Materials: stainless steel,carbon steel,iron
- Size: L2300*W820*H1420
- Color: Yellow
- Exports to: Mainland China, Africa, Middle East, Southeast Asia, South Asia, Central Asia, USA and Canada, Latin America, Russia, Other European Countries, Japan and South Korea, Hong Kong China, Macao China and Taiwan China, Others
- Made in: Sichuan, China
Product details
| Materials | stainless steel,carbon steel,iron |
|---|---|
| Size | L2300*W820*H1420 |
| Color | Yellow |
Product details
| Materials | stainless steel,carbon steel,iron |
|---|---|
| Size | L2300*W820*H1420 |
| Color | Yellow |
From the supplier
Technical Specification:
Item
YZYX140(-8)
YZYX140CJ
YZYX140CJGX
Revolving speed of spiral axis (r/min)
30-40
Power required（kw）
18.5（Y180M-4）or 22（Y180L-4）
Measurement (mm)
2010×690×1430
2100×690×1400
2300×820×1370
Weight (kg)
806
884
1100
Note:
This weight is without electro-motor’s weight.
Main technique features:
Below features are based on oil plants with above average quality smoothly and continuously hot squeezed with all auxiliary equipments after good pretreatments, such as screening, husking, flaking and cooking, etc.
Oil Plants
Processing Capacity (t/24h)
Oil content of
Dry cakes (%)
Oil yield efficiency (%)
Electric power consumption (kw.h/t)
Rapeseed
9~11
≤7.6
≥82
≤34
Cotton seeds
9~11
≤6.8
≥77
≤54
Soybean
8~10
≤6.5
≥67
≤51
Peanut
9~11
≤6.5
≥92.3
≤34
Performance Characteristics:
Our series YZYX140 spiral oil press is suitable for squeezing vegetable oil from rapeseed, cottonseed, soybean, shelled peanut, flax seed, tung oil seed, sunflower seed and palm kernel, etc. The product has characters of small investment, high capacity, strong compatibility and high efficiency. It is widely used in small oil refinery and rural enterprise.
YZYX140 is basic 2-step-squeezing spiral oil press.
YZYX140-8 is 3-step squeezing spiral oil press with bigger compression ratio in the press chest, suitable for users who have operation experience and stress on low oil content of the dry cakes.
YZYX140CJ is a strong pressing type in which the pressure is big. Thus, the squeezing effect is better when operates properly.
YZYX140GX has bigger deceleration box which operates smoothly and has long service life.
From the supplier
Technical Specification:
Item
YZYX140(-8)
YZYX140CJ
YZYX140CJGX
Revolving speed of spiral axis (r/min)
30-40
Power required（kw）
18.5（Y180M-4）or 22（Y180L-4）
Measurement (mm)
2010×690×1430
2100×690×1400
2300×820×1370
Weight (kg)
806
884
1100
Note:
This weight is without electro-motor’s weight.
Main technique features:
Below features are based on oil plants with above average quality smoothly and continuously hot squeezed with all auxiliary equipments after good pretreatments, such as screening, husking, flaking and cooking, etc.
Oil Plants
Processing Capacity (t/24h)
Oil content of
Dry cakes (%)
Oil yield efficiency (%)
Electric power consumption (kw.h/t)
Rapeseed
9~11
≤7.6
≥82
≤34
Cotton seeds
9~11
≤6.8
≥77
≤54
Soybean
8~10
≤6.5
≥67
≤51
Peanut
9~11
≤6.5
≥92.3
≤34
Performance Characteristics:
Our series YZYX140 spiral oil press is suitable for squeezing vegetable oil from rapeseed, cottonseed, soybean, shelled peanut, flax seed, tung oil seed, sunflower seed and palm kernel, etc. The product has characters of small investment, high capacity, strong compatibility and high efficiency. It is widely used in small oil refinery and rural enterprise.
YZYX140 is basic 2-step-squeezing spiral oil press.
YZYX140-8 is 3-step squeezing spiral oil press with bigger compression ratio in the press chest, suitable for users who have operation experience and stress on low oil content of the dry cakes.
YZYX140CJ is a strong pressing type in which the pressure is big. Thus, the squeezing effect is better when operates properly.
YZYX140GX has bigger deceleration box which operates smoothly and has long service life.
