YZYX130WZ Combined Oil Press with Vacuum Oil Filter in one
Mian Yang Guang Xin Import & Export Co.,Ltd
The supplier hasn’t listed a price. We can get their current prices and MOQ.
Verify from $29 · written report in 3 business days · 100% refund if not satisfied
YZYX130WZ Combined Oil Press with Vacuum Oil Filter in one
Mian Yang Guang Xin Import & Export Co.,LtdThe supplier hasn’t listed a price. We can get their current prices and MOQ.
Verify from $29 · written report in 3 business days · 100% refund if not satisfied
About this product
- Materials: stainless steel,carbon steel,iron
- Size: L2005*W1610*H2010
- Color: Green
- Exports to: Mainland China, Africa, Middle East, Southeast Asia, South Asia, Central Asia, USA and Canada, Latin America, Russia, Other European Countries, Japan and South Korea, Hong Kong China, Macao China and Taiwan China, Others
- Made in: Sichuan, China
About this product
- Materials: stainless steel,carbon steel,iron
- Size: L2005*W1610*H2010
- Color: Green
- Exports to: Mainland China, Africa, Middle East, Southeast Asia, South Asia, Central Asia, USA and Canada, Latin America, Russia, Other European Countries, Japan and South Korea, Hong Kong China, Macao China and Taiwan China, Others
- Made in: Sichuan, China
Product details
| Materials | stainless steel,carbon steel,iron |
|---|---|
| Size | L2005*W1610*H2010 |
| Color | Green |
Product details
| Materials | stainless steel,carbon steel,iron |
|---|---|
| Size | L2005*W1610*H2010 |
| Color | Green |
From the supplier
Technical Specification:
Item
YZYX130-（2, 8, 9,10,12）WZ
Revolving speed of spiral axis (r/min)
30-40
Power of main electromotor (kw)
18.5
Electrical power of filtration (kw)
2.2
Power for temperature controlling (kw)
≥3.2
Measurement (mm)
2005*1610*2010
Weight (kg)
1280
Main technique features:
Below features are based on oil plants with above average quality smoothly and continuously hot squeezed with all auxiliary equipments after good pretreatments, such as screening, husking, flaking and cooking, etc.
Oil Plants
Processing Capacity（t/24h）
Oil content of
Dry cakes
（％）
Oil yield
efficiency
（％）
Electricity consumption（kW·h/t）
Rapeseed
≥8.0
≤7.6
≥82
≤40
Cotton seeds
≥8.0
≤6.8
≥77
-
Soybean
≥7.0
≤6.5
≥67
≤56
Groundnut
≥8.0
≤6.5
≥92.3
≤39
Performance Characteristics:
The series YZYX130WZ combined oil presses are developed on the basis of the single machine to meet the market demands. The function of auto-heating the press cage has replaced the traditional way by squeezing residue cake, which could shorten the preparation work, reduce the energy consumption and abrasion, and thus lengthen the durability. When the squeezing is suspended, the temperature can be maintained by this system. In the meanwhile, this machine was added with filtration function. The crude oil discharged from the press cage will directly be filtrated by the vacuum filtration system. Comparing with the traditional plate frame filtration machine, the vacuum filtration machine is lighter, easier to operate and more convenient to clean the residue (so the residue can be re-squeezed in time if necessary). The structure of this combined oil press is compact, only requires a small working place and saves labor. It is ideal cooking oil equipment for small oil refinery use, processing oil in rural and urban bazaars or processing material supplied by clients in rural area.
From the supplier
Technical Specification:
Item
YZYX130-（2, 8, 9,10,12）WZ
Revolving speed of spiral axis (r/min)
30-40
Power of main electromotor (kw)
18.5
Electrical power of filtration (kw)
2.2
Power for temperature controlling (kw)
≥3.2
Measurement (mm)
2005*1610*2010
Weight (kg)
1280
Main technique features:
Below features are based on oil plants with above average quality smoothly and continuously hot squeezed with all auxiliary equipments after good pretreatments, such as screening, husking, flaking and cooking, etc.
Oil Plants
Processing Capacity（t/24h）
Oil content of
Dry cakes
（％）
Oil yield
efficiency
（％）
Electricity consumption（kW·h/t）
Rapeseed
≥8.0
≤7.6
≥82
≤40
Cotton seeds
≥8.0
≤6.8
≥77
-
Soybean
≥7.0
≤6.5
≥67
≤56
Groundnut
≥8.0
≤6.5
≥92.3
≤39
Performance Characteristics:
The series YZYX130WZ combined oil presses are developed on the basis of the single machine to meet the market demands. The function of auto-heating the press cage has replaced the traditional way by squeezing residue cake, which could shorten the preparation work, reduce the energy consumption and abrasion, and thus lengthen the durability. When the squeezing is suspended, the temperature can be maintained by this system. In the meanwhile, this machine was added with filtration function. The crude oil discharged from the press cage will directly be filtrated by the vacuum filtration system. Comparing with the traditional plate frame filtration machine, the vacuum filtration machine is lighter, easier to operate and more convenient to clean the residue (so the residue can be re-squeezed in time if necessary). The structure of this combined oil press is compact, only requires a small working place and saves labor. It is ideal cooking oil equipment for small oil refinery use, processing oil in rural and urban bazaars or processing material supplied by clients in rural area.
