YZYX120SLWZ Combined Oil Press with Water Cooling System with Vacuum Oil Filter
Mian Yang Guang Xin Import & Export Co.,Ltd
The supplier hasn’t listed a price. We can get their current prices and MOQ.
Verify from $29 · written report in 3 business days · 100% refund if not satisfied
YZYX120SLWZ Combined Oil Press with Water Cooling System with Vacuum Oil Filter
Mian Yang Guang Xin Import & Export Co.,LtdThe supplier hasn’t listed a price. We can get their current prices and MOQ.
Verify from $29 · written report in 3 business days · 100% refund if not satisfied
About this product
- Materials: stainless steel,carbon steel,iron
- Size: L2120*W1350*H1940
- Color: Green
- Exports to: Mainland China, Africa, Middle East, Southeast Asia, South Asia, Central Asia, USA and Canada, Latin America, Russia, Other European Countries, Japan and South Korea, Hong Kong China, Macao China and Taiwan China, Others
- Made in: Sichuan, China
About this product
- Materials: stainless steel,carbon steel,iron
- Size: L2120*W1350*H1940
- Color: Green
- Exports to: Mainland China, Africa, Middle East, Southeast Asia, South Asia, Central Asia, USA and Canada, Latin America, Russia, Other European Countries, Japan and South Korea, Hong Kong China, Macao China and Taiwan China, Others
- Made in: Sichuan, China
Product details
| Materials | stainless steel,carbon steel,iron |
|---|---|
| Size | L2120*W1350*H1940 |
| Color | Green |
Product details
| Materials | stainless steel,carbon steel,iron |
|---|---|
| Size | L2120*W1350*H1940 |
| Color | Green |
From the supplier
Technical Specification:
Item
YZYX120SLWZ
Revolving speed of spiral axis (r/min)
37-45
Power of main electromotor (kw)
11-15
Electrical power of filtration (kw)
2.2
Power for temperature controlling (kw)
1.5
Power of cooling system (kw)0.12-0.16Measurement (mm)
2420*1765*1940
Weight (kg)
1280
Main technique features:
Below features are based on oil plants with above average quality smoothly and continuously hot squeezed with all auxiliary equipments after good pretreatments, such as screening, husking, flaking and cooking, etc.
Oil Plants
Processing Capacity（t/24h）
Oil content of
Dry cakes
（％）
Oil yield
efficiency
（％）
Electricity consumption（kW·h/t）
Rapeseed
≥7.0
≤7.0
≥82
≤40
Cotton seeds
≥7.0
≤6.5
≥77
-
Soybean
≥6.0
≤6.0
≥67
≤56
Groundnut
≥7.0
≤7.0
≥92.3
≤39
Performance Characteristics:
YZYX120SLWZ automatic temperature controlled combined oil presse is based 120JWZ, with electric heating device and a circulating water cooling system to control oil press chamber temperature, so as to achieve constant temperature for extracting oil, keep pressing chamber pressure stable (according to different oil, pressing chamber temperature maintained at 120-140 degrees C), avoid the temperature too high during long time work, the protein degeneration, material coking, so the oil yield is improved, and a variety of vitamins, fatty acids, minerals, trace elements and nutrients could be intact. At the same time, the cake utilization value ,the degree of intelligence and automation are improved.
The product has been a number of national patents (patent number ZL 201020677033.7, ZL 20142 0279178.X).
From the supplier
Technical Specification:
Item
YZYX120SLWZ
Revolving speed of spiral axis (r/min)
37-45
Power of main electromotor (kw)
11-15
Electrical power of filtration (kw)
2.2
Power for temperature controlling (kw)
1.5
Power of cooling system (kw)0.12-0.16Measurement (mm)
2420*1765*1940
Weight (kg)
1280
Main technique features:
Below features are based on oil plants with above average quality smoothly and continuously hot squeezed with all auxiliary equipments after good pretreatments, such as screening, husking, flaking and cooking, etc.
Oil Plants
Processing Capacity（t/24h）
Oil content of
Dry cakes
（％）
Oil yield
efficiency
（％）
Electricity consumption（kW·h/t）
Rapeseed
≥7.0
≤7.0
≥82
≤40
Cotton seeds
≥7.0
≤6.5
≥77
-
Soybean
≥6.0
≤6.0
≥67
≤56
Groundnut
≥7.0
≤7.0
≥92.3
≤39
Performance Characteristics:
YZYX120SLWZ automatic temperature controlled combined oil presse is based 120JWZ, with electric heating device and a circulating water cooling system to control oil press chamber temperature, so as to achieve constant temperature for extracting oil, keep pressing chamber pressure stable (according to different oil, pressing chamber temperature maintained at 120-140 degrees C), avoid the temperature too high during long time work, the protein degeneration, material coking, so the oil yield is improved, and a variety of vitamins, fatty acids, minerals, trace elements and nutrients could be intact. At the same time, the cake utilization value ,the degree of intelligence and automation are improved.
The product has been a number of national patents (patent number ZL 201020677033.7, ZL 20142 0279178.X).
