About this product
- Materials: stainless steel
- Size: 4500*1800*2200
- Color: S.S
- Exports to: Mainland China, Africa, Middle East, Southeast Asia, South Asia, Central Asia, USA and Canada, Latin America, Russia, EU, Other European Countries, Japan and South Korea, Hong Kong China, Macao China and Taiwan China, Others
- Made in: Jiangsu, China
About this product
- Materials: stainless steel
- Size: 4500*1800*2200
- Color: S.S
- Exports to: Mainland China, Africa, Middle East, Southeast Asia, South Asia, Central Asia, USA and Canada, Latin America, Russia, EU, Other European Countries, Japan and South Korea, Hong Kong China, Macao China and Taiwan China, Others
- Made in: Jiangsu, China
Product details
| Materials | stainless steel |
|---|---|
| Size | 4500*1800*2200 |
| Color | S.S |
From the supplier
THIS MACHINE USE TO WRAP CONE SHAPE CHOCOLATE,IN SINGLE TWIST STYLE,WITH AUTOMATIC FEEDING SYSTEM,SAVE WORKER AND SAVE TIME,SERVO MOTOR CONTROL FOR PAPER FEEDING.
THE PACKING MACHINE CLEANS UP EVERY DAY. YOU CAN'T GET GOOD MACHINE PERFORMANCE WITHOUT CLEANING. THE MECHANICAL PARTS OF THE MACHINE WORK NEED TO BE LUBRICATED. WHEN YOU SOLVE THIS PROBLEM YOUR MACHINE WILL WORK PROPERLY. SPECIFICATION TABLE * PACKING TYPE: SINGLE-HEAD KNOTTED * SHAFT SYSTEM CONNECTED IS THE GEAR TRANSMISSION LINE, HANDWHEEL FOR CLOCKWISE ROTATION * AUTOMATIC RAIN SYSTEM LUBRICATION, TO ENSURE THAT THE MECHANICAL TRANSMISSION OF THE PARTS OF THE LUBRICATION * PACKAGING SPEED IS UP TO 200 PER MINUTE, DEPENDING ON THE CHANGE BETWEEN THE SHAPE OF THE CHOCOLATE. * THIS MACHINE FEED IS THE REQUIRED LENGTH DUE TO THE SERVO MOTOR TO PROVIDE POWER. * PACKAGING MATERIALS OUTER PAPER PEP THICK 0.03 PAPER FOR DEWAXING THICKNESS 0.03
TECHNICAL PARAMETERS
CHOCOLATE SIZE RANGE: DIAMETER FROM 15 TO 40MM.
HEIGHT RANGE: FROM 12 TO 37MM
FILM: OUTSIDE:PEP, 0.03MM,
INNER PAPER: DIPPED WAX 0.03MM
TOTAL POWER: 5.5KW
MAIN MOTOR: 2.2KW
CONVRYOR MOTOR: 0.37KW*4,380V,3 PHASE, 50HZ
PACKING SPEED: 150-200PCS/MIN
DIMENSION: 4500*1800*2200MM
WEIGHT: 2000KG
