YH Series Automatic Clothes Screen Printing Machine

10/10 fairsForeign Trade CompanyModel YH
YH Series Automatic Clothes Screen Printing Machine
Price on request

The supplier hasn’t listed a price. We can get their current prices and MOQ.

Get a quote from this supplierSee all sourcing services
Service
From $29 per supplier (Verify)
You get
Phone and video verification, a quote sheet and a written report
Turnaround
3 business days
Contact details
Sent to you once your request is confirmed

If we can't reach the supplier within 3 business days, we refund the fee.

About this product

  • Materials: Metal
  • Size: φ4800*1650~φ7000*2500
  • Color: blue
  • Exports to: Mainland China, Africa, Middle East, Southeast Asia, South Asia, Central Asia, USA and Canada, Latin America, Russia, EU, Other European Countries, Japan and South Korea, Hong Kong China, Macao China and Taiwan China, Others
  • Made in: Zhejiang, China

Product details

MaterialsMetal
Sizeφ4800*1650~φ7000*2500
Colorblue

From the supplier

Introduce：



YH series printing machine is the newest and most advanced new generation automatic printing equipment in China, which will bring you high output and fast investment return. Its main features include:computer micro-processing system,accurate printing color setting accuracy,electric printing head and pneumatic turntable lifting system, simple and fast net frame loading and unloading, independent scraping and printing ink recovery speed can be adjusted freely, the machine frame can install flocking printing head and vivid touch screen operation interface.The YH series is available in 4,6,8,10,12 and 14 colors,with a maximum printing area of 500 x 700 mm. All models can be printed on t-shirts, sleeves, sheets and textile bags.



Features:



1.Color touch screen operation interface



2.The servo drive system can provide high speed running speed while ensuring stable, durable and long service life of printing



3.Quick pneumatic plat form replacement function



4.The turntable can rotate clockwise or counterclockwise



5.The net distance of all stations(the distance between the screen plate and the substrate surface) can be accurately adjusted at the same time



6.The frame should be able to assemble oven, printing head and flocking printing head as required



7.Manual tap jumping switch can avoid empty platform printing



8.Double shift function improves printing quality



9.The function of thick plate printing and automatic plate-changing is optional



  • 10. One-year warranty, life time maintenance



Technical parameter：

Model

SPO-6/24

SPO-8/30

SPO-10/36

SPO-12/42

SPO-14/48

SPO-16/54

SPO-18/60

SPO-20/66

Color/Station

6

8

10

12

14

16

18

20

Max print area

24

30

36

42

48

54

60

66

Pallet Size

500*700mm(台板 600*800mm）

Max frame size

700*900mm(大小网框可用)

Max air consumption

4.2Kw

5.0Kw

5.8Kw

6.6Kw

7.4Kw

8.2Kw

9.0Kw

9.8Kw

Printing motor power

0.4Kw

Max output

12.4Kw

Main motor power

AC380V/3PH/50HZ

Each motor power

0.6/0.8Mpa

Dimension

0.20m³/m

0.25m³/m

0.30m³/m

0.35m³/m

0.40m³/m

0.45m³/m

0.50m³/m

0.55m³/m

Weight

11200*3560*1680

13250*3560*1680

15300*3560*1680

17350*3560*1680

19400*3560*1680

21450*3560*1680

23500*3560*1680

25550*3560*1680

Model

3300kg

3800kg

4300kg

4800kg

5300kg

5800kg

6300kg

6800kg
