YC series single phase ac electric motor
The supplier hasn’t listed a price. We can get their current prices and MOQ.
Verify from $29 · written report in 3 business days · 100% refund if unreachable
YC series single phase ac electric motor
The supplier hasn’t listed a price. We can get their current prices and MOQ.
Verify from $29 · written report in 3 business days · 100% refund if unreachable
About this product
- Materials: cast iron housing，100% copper
- Size: depends
- Color: depends
- Power type: Other
- Stroke: Other
- Cylinder: Other
- Exports to: Africa, Middle East, Southeast Asia, South Asia, Central Asia, USA and Canada, Latin America, Russia, EU, Other European Countries, Japan and South Korea, Hong Kong China, Macao China and Taiwan China, Others
- Made in: Fujian, China
About this product
- Materials: cast iron housing，100% copper
- Size: depends
- Color: depends
- Power type: Other
- Stroke: Other
- Cylinder: Other
- Exports to: Africa, Middle East, Southeast Asia, South Asia, Central Asia, USA and Canada, Latin America, Russia, EU, Other European Countries, Japan and South Korea, Hong Kong China, Macao China and Taiwan China, Others
- Made in: Fujian, China
Product details
| Materials | cast iron housing，100% copper |
|---|---|
| Size | depends |
| Color | depends |
| Power type | Other |
| Stroke | Other |
| Cylinder | Other |
Product details
| Materials | cast iron housing，100% copper |
|---|---|
| Size | depends |
| Color | depends |
| Power type | Other |
| Stroke | Other |
| Cylinder | Other |
From the supplier
YC series single phase ac electric motor
Operating condition
- Ambient temperature: -15℃≤θ≤40℃
- Altitude: ≤1000m
- Protection class: IP44
- Insulation class: B/F
- Rated voltage: 220V, other voltage on request
- Cooling type: IC 0141
- Duty: Continuous(S1)
- Rated frequency: 50HZ, other frequency on request.
Technical data
Type
Out
put
Voltage(V)Current
(A)Freq.
(Hz)Power
factorEff(%)Speed
(r/min)Tstart/TnIst/InTmax/TnkWHPYC80A-20.370.52203.3500.746628403.06.51.8YC80B-20.550.752204.7500.746728503.06.51.8YC80C-20.7512206.1500.756828502.871.8YC90S-21.11.522010.5500.87028802.871.8YC90L-21.5222012.4500.827329002.871.8YC100L-22.2322018.8500.827429002.671.8YC112M1-23422021.4500.847629002.271.8YC112M2-23.7522024.8500.867929002.271.8YC80B-40.370.52204.1500.645614203.061.8YC80C-40.550.752205.6500.656014303.061.8YC90S-40.7512208.3500.726314402.86.51.8YC90L-41.11.522011.2500.726714502.86.51.8YC100L-41.5222012.5500.737214602.86.51.8YC112M-42.2322018.3500.747314702.66.51.8YC132SA-43422019500.87614602.26.51.8YC132SB-43.7522022500.827914602.26.51.8YC132M1-45.57.522032.5500.958114602.06.51.8YC132M2-47.51022040500.958314602.06.51.8
Packaging & Shipping
FAQ
Q: Do you offer OEM service?
A: Yes
Q: What is your payment term?
A: 30% T/T in advance, 70% balance when receiving B/L copy. Or irrevocable L/C.
Q: What is your lead time?
A: About 30 days after receiving deposit or original L/C.
Q: What certifiicates do you have?
A: We have CE, ISO. And we can apply for specific certificate for different country such as SONCAP for Nigeria, COI for Iran, SASO for Saudi Arabia, etc
Our Services
What we do:
1.Stamping of lamination
2.Rotor die-casting
3.Winding and inserting – both manual and semi-automatically
4.Vacuum varnishing
5.Machining shaft, housing, end shields, etc…
6.Rotor balancing
7.Painting – both wet paint and powder coating
8.assembly
9.Packing
10.Inspecting spare parts every processing
11.100% test after each process and final test before packing.
From the supplier
YC series single phase ac electric motor
Operating condition
- Ambient temperature: -15℃≤θ≤40℃
- Altitude: ≤1000m
- Protection class: IP44
- Insulation class: B/F
- Rated voltage: 220V, other voltage on request
- Cooling type: IC 0141
- Duty: Continuous(S1)
- Rated frequency: 50HZ, other frequency on request.
Technical data
Type
Out
put
Voltage(V)Current
(A)Freq.
(Hz)Power
factorEff(%)Speed
(r/min)Tstart/TnIst/InTmax/TnkWHPYC80A-20.370.52203.3500.746628403.06.51.8YC80B-20.550.752204.7500.746728503.06.51.8YC80C-20.7512206.1500.756828502.871.8YC90S-21.11.522010.5500.87028802.871.8YC90L-21.5222012.4500.827329002.871.8YC100L-22.2322018.8500.827429002.671.8YC112M1-23422021.4500.847629002.271.8YC112M2-23.7522024.8500.867929002.271.8YC80B-40.370.52204.1500.645614203.061.8YC80C-40.550.752205.6500.656014303.061.8YC90S-40.7512208.3500.726314402.86.51.8YC90L-41.11.522011.2500.726714502.86.51.8YC100L-41.5222012.5500.737214602.86.51.8YC112M-42.2322018.3500.747314702.66.51.8YC132SA-43422019500.87614602.26.51.8YC132SB-43.7522022500.827914602.26.51.8YC132M1-45.57.522032.5500.958114602.06.51.8YC132M2-47.51022040500.958314602.06.51.8
Packaging & Shipping
FAQ
Q: Do you offer OEM service?
A: Yes
Q: What is your payment term?
A: 30% T/T in advance, 70% balance when receiving B/L copy. Or irrevocable L/C.
Q: What is your lead time?
A: About 30 days after receiving deposit or original L/C.
Q: What certifiicates do you have?
A: We have CE, ISO. And we can apply for specific certificate for different country such as SONCAP for Nigeria, COI for Iran, SASO for Saudi Arabia, etc
Our Services
What we do:
1.Stamping of lamination
2.Rotor die-casting
3.Winding and inserting – both manual and semi-automatically
4.Vacuum varnishing
5.Machining shaft, housing, end shields, etc…
6.Rotor balancing
7.Painting – both wet paint and powder coating
8.assembly
9.Packing
10.Inspecting spare parts every processing
11.100% test after each process and final test before packing.
