XinRan Xinran low pressure oil-free screw air compressor
SUMEC INTERNATIONAL TECHNOLOGY CO.,LTD
The supplier hasn’t listed a price. We can get their current prices and MOQ.
Verify from $29 · written report in 3 business days · 100% refund if not satisfied
XinRan Xinran low pressure oil-free screw air compressor
SUMEC INTERNATIONAL TECHNOLOGY CO.,LTDThe supplier hasn’t listed a price. We can get their current prices and MOQ.
Verify from $29 · written report in 3 business days · 100% refund if not satisfied
About this product
- Power source: Other
- Configuration: Other
- Performance: Other
- Material: Other
- Application: Other
- Lubrication style: Other
- Exports to: Mainland China, Africa, Middle East, Southeast Asia, South Asia, Central Asia, USA and Canada, Latin America, Russia, EU, Other European Countries, Oceania, Japan and South Korea
- Made in: City, Shanghai, China
About this product
- Power source: Other
- Configuration: Other
- Performance: Other
- Material: Other
- Application: Other
- Lubrication style: Other
- Exports to: Mainland China, Africa, Middle East, Southeast Asia, South Asia, Central Asia, USA and Canada, Latin America, Russia, EU, Other European Countries, Oceania, Japan and South Korea
- Made in: City, Shanghai, China
Product details
| Power source | Other |
|---|---|
| Configuration | Other |
| Performance | Other |
| Material | Other |
| Application | Other |
| Lubrication style | Other |
| Mute | Not MuteMute |
| Piston type | Other |
Product details
| Power source | Other |
|---|---|
| Configuration | Other |
| Performance | Other |
| Material | Other |
| Application | Other |
| Lubrication style | Other |
| Mute | Not MuteMute |
| Piston type | Other |
From the supplier
Xinran brand low pressure oilless screw air compressor. This machine is a single-stage low pressure oil-free screw air compressor. Low-pressure compressed air is often a critical factor in the production process: dust and bulk transportation, fermentation, air separation, water treatment, material mixing, ventilation, drying and cooling processes; overall production reliability is your key concern. By using dedicated low pressure air compressors, you can achieve significant process improvements in your low pressure application systems: XRA(air-cooled)/XRW(water-cooled).
exhaust volume
6.7-45m³/min
power
30-185kW
exhaust pressure
0.2-0.6MPa
application range
Single-stage low-pressure oil-free series screw air compressors are suitable for the transportation and compression of industrial and process gases, such as nitrogen, acetylene, butadiene, chloroform gas, limestone kiln gas, coke oven gas, hydrogen, coal gas, methane, propane, hydrogen sulfide gas, carbon monoxide and other gases or mixed gases.
parameter table
modelMax. Working pressure (MPa)Flow rate (m3/min)Power (kW/HP)Noise Level (DB)Lubricating water volumesize (length × width × height)
(mm)Weight (kg)
S30A/XR
0.46.730/4066501650×1180×1505(A) 500×1080×1300(W)1200S37A/XR
0.48.637/5066601650×1180×1505(A) 1500×1080×1300(W)1300S45A/XR
0.410.545/60681201800×1360×16701500S55A/XR
0.413.555/75691601800×1360×16701670S75A/XR
0.419.975/100721601800×1360×16701300S90A/XR
0.423.990/120731802200×1550×18002550S110A/XR
0.428.2110/150771802200×1550×18002600S132A/XR
0.430132/180771802200×1550×18002800S160A/XR
0.436160/220792303000×1800×21004000S185A/XR
0.445185/250792303000×1800×21004350Note: "A" stands for air cooling;"W" stands for water cooling;
characteristics
Oil-free air screw elements
Rotor is coated
Includes all items: outlet air muffler, built-in starter, sound insulation cover (standard version), pre-installed distribution box, check valve, IP55 motor, waterproof and dustproof, vibration reduction outlet
From the supplier
Xinran brand low pressure oilless screw air compressor. This machine is a single-stage low pressure oil-free screw air compressor. Low-pressure compressed air is often a critical factor in the production process: dust and bulk transportation, fermentation, air separation, water treatment, material mixing, ventilation, drying and cooling processes; overall production reliability is your key concern. By using dedicated low pressure air compressors, you can achieve significant process improvements in your low pressure application systems: XRA(air-cooled)/XRW(water-cooled).
exhaust volume
6.7-45m³/min
power
30-185kW
exhaust pressure
0.2-0.6MPa
application range
Single-stage low-pressure oil-free series screw air compressors are suitable for the transportation and compression of industrial and process gases, such as nitrogen, acetylene, butadiene, chloroform gas, limestone kiln gas, coke oven gas, hydrogen, coal gas, methane, propane, hydrogen sulfide gas, carbon monoxide and other gases or mixed gases.
parameter table
modelMax. Working pressure (MPa)Flow rate (m3/min)Power (kW/HP)Noise Level (DB)Lubricating water volumesize (length × width × height)
(mm)Weight (kg)
S30A/XR
0.46.730/4066501650×1180×1505(A) 500×1080×1300(W)1200S37A/XR
0.48.637/5066601650×1180×1505(A) 1500×1080×1300(W)1300S45A/XR
0.410.545/60681201800×1360×16701500S55A/XR
0.413.555/75691601800×1360×16701670S75A/XR
0.419.975/100721601800×1360×16701300S90A/XR
0.423.990/120731802200×1550×18002550S110A/XR
0.428.2110/150771802200×1550×18002600S132A/XR
0.430132/180771802200×1550×18002800S160A/XR
0.436160/220792303000×1800×21004000S185A/XR
0.445185/250792303000×1800×21004350Note: "A" stands for air cooling;"W" stands for water cooling;
characteristics
Oil-free air screw elements
Rotor is coated
Includes all items: outlet air muffler, built-in starter, sound insulation cover (standard version), pre-installed distribution box, check valve, IP55 motor, waterproof and dustproof, vibration reduction outlet
