Vertical Fine Boring & Milling-Grinding Machine
XI'AN AMCO MACHINE TOOLS CO.,LTD
The supplier hasn’t listed a price. We can get their current prices and MOQ.
Verify from $29 · written report in 3 business days · 100% refund if not satisfied
Vertical Fine Boring & Milling-Grinding Machine
XI'AN AMCO MACHINE TOOLS CO.,LTDThe supplier hasn’t listed a price. We can get their current prices and MOQ.
Verify from $29 · written report in 3 business days · 100% refund if not satisfied
About this product
- Materials: Metal
- Size: 2000*1300*1600
- Color: red
- Control type: Other
- Warranty: 1 Year
- Power: Other
- Exports to: Mainland China, Africa, Middle East, Southeast Asia, South Asia, Central Asia, USA and Canada, Latin America, Russia, EU, Other European Countries, Japan and South Korea, Hong Kong China, Macao China and Taiwan China, Others
About this product
- Materials: Metal
- Size: 2000*1300*1600
- Color: red
- Control type: Other
- Warranty: 1 Year
- Power: Other
- Exports to: Mainland China, Africa, Middle East, Southeast Asia, South Asia, Central Asia, USA and Canada, Latin America, Russia, EU, Other European Countries, Japan and South Korea, Hong Kong China, Macao China and Taiwan China, Others
Product details
| Materials | Metal |
|---|---|
| Size | 2000*1300*1600 |
| Color | red |
| Control type | Other |
| Warranty | 1 Year |
| Power | Other |
Product details
| Materials | Metal |
|---|---|
| Size | 2000*1300*1600 |
| Color | red |
| Control type | Other |
| Warranty | 1 Year |
| Power | Other |
From the supplier
MAIN FEATURE
1.Stepless of spindle turning,feeding.
2.Rotating speed snd feed of spindle is free-setup,automatical returning of spindle can be realized.
3.Longitudingal and cross movement of table
4.Complete set of accessories of boring,drilling & reaming and easy exchange
5.Spindle fast centering device
6.Tool measuring device
7.Boring depth contorl device.
8.Table with digital readout for jig borer machine
Specification
ModelTXM170ATXM200ATXM250AMax.Boring Diameter170mm200mm250mmMax. Boring Depth400mm500mm500mmMax. Grinding Area400x1000mmMax. Milling Area400x1000mmMax. Milling & Reaming Diameter30mmSpindle Speed120-1200r/minFeeding of the Spindle14-900mm/minRapid Moving Speed of Spindle900mm/minSpindle Travel700mmDistance Between Spindle End Face and Table0-700mmDistance Between Spindle Axis and Carriage Vertical Plane375mmLongitudinal Feed of Worktable32-1350mm/minRapid Moving Speed of Worktable Longitudinal Travel1350mm/minLongitudinal Travel of Worktable1500mmTransversal Travel of Worktable200mmWorktable Dimension500x1250mm500x1500mm500x1500mmMain Motor5.5kwProcessing RoughnessBoringRa 2.5umMillingRa 3.2umGrindingRa 0.8mmOverall Dimension2600x1630x2300mmPacking Dimension2230x1870x2270mmNet/Gross Weight3300/3600kg3500/3800kg3500/3800kgFrom the supplier
MAIN FEATURE
1.Stepless of spindle turning,feeding.
2.Rotating speed snd feed of spindle is free-setup,automatical returning of spindle can be realized.
3.Longitudingal and cross movement of table
4.Complete set of accessories of boring,drilling & reaming and easy exchange
5.Spindle fast centering device
6.Tool measuring device
7.Boring depth contorl device.
8.Table with digital readout for jig borer machine
Specification
ModelTXM170ATXM200ATXM250AMax.Boring Diameter170mm200mm250mmMax. Boring Depth400mm500mm500mmMax. Grinding Area400x1000mmMax. Milling Area400x1000mmMax. Milling & Reaming Diameter30mmSpindle Speed120-1200r/minFeeding of the Spindle14-900mm/minRapid Moving Speed of Spindle900mm/minSpindle Travel700mmDistance Between Spindle End Face and Table0-700mmDistance Between Spindle Axis and Carriage Vertical Plane375mmLongitudinal Feed of Worktable32-1350mm/minRapid Moving Speed of Worktable Longitudinal Travel1350mm/minLongitudinal Travel of Worktable1500mmTransversal Travel of Worktable200mmWorktable Dimension500x1250mm500x1500mm500x1500mmMain Motor5.5kwProcessing RoughnessBoringRa 2.5umMillingRa 3.2umGrindingRa 0.8mmOverall Dimension2600x1630x2300mmPacking Dimension2230x1870x2270mmNet/Gross Weight3300/3600kg3500/3800kg3500/3800kgAbout the supplier
