About this product
- Materials: Plastic Water Meter
- Size: DN15~25mm
- Color: blue,black
- Exports to: Africa, Middle East, Southeast Asia, South Asia, Central Asia, USA and Canada, Latin America, Russia, EU, Other European Countries, Japan and South Korea, Hong Kong China, Macao China and Taiwan China
About this product
- Materials: Plastic Water Meter
- Size: DN15~25mm
- Color: blue,black
- Exports to: Africa, Middle East, Southeast Asia, South Asia, Central Asia, USA and Canada, Latin America, Russia, EU, Other European Countries, Japan and South Korea, Hong Kong China, Macao China and Taiwan China
Product details
| Materials | Plastic Water Meter |
|---|---|
| Size | DN15~25mm |
| Color | blue,black |
From the supplier
Overview
It is a metering instrument to continuously measure, record and display volume of water flflowing through sensor by use of ultrasonic time difference method
Features
- Accuracy R250 (R400 optional)
- No mechanical moving parts, no abrades
- Battery life ≥6 years
- Bi-directional Measuring
- Outline Dimensional Drawing Dimension DN Length (L) Length with connections Width (W) Height (H) Connection mm d (Pipe) D(Meter) 15 110 205 67 90 R1/2 G3/4B 165 260 67 90 R1/2 G3/4B 20 130 235 67 95 R3/4 G1B 195 300 67 95 R3/4 G1B 25 195 300 67 100 R1 G1 1/4B Technical Data Item Unit Details Nominal Diameter mm 15 20 25 Q3/Q1 R400 Overload Flow Rate (Q4) m3 /h 3.125 5 7.875 Permanent Flow Rate (Q3) m3 /h 2.5 4 6.3 Transitional Flow Rate (Q2) L/h 10 1.6 25.2 Minimum Flow Rate (Q1) L/h 6.25 1 15.75 Starting Flow Rate L/h 1 Accuracy Class Class 2 Temperature Class T50 Maximum Admissible Pressure PN16 Pressure Loss Classes △P25 Electromagnetic Environmental Class E1 Environmental Classifification O Protection Class IP68 Installation Direction All installation positions Flow Profifile Sensitivity Class U5/D3 (U0/D0 Customizable) Battery Lifetime ≥ 6 years Display LCD, 9 digits + additional characters
