TUF-2000B DN50-DN700 External Clamp Type Plug-in Wall-mounted Ultrasonic Flowmeter
Dalian Teren Instruments Co.,Ltd
See what’s includedHide breakdown
- FOB goods (100)
- $10,500
- Ocean freight + handling (2.6 CBM, volume guessed from price)
- $1,015
- US duty (3.5%)
- $368
- Section 301 tariff (25.0%)
- $2,625
- Customs fees (MPF/HMF)
- $49
Estimate in USD to a US port using category averages, rates as of 2026-09. Other countries on request. A quote from our desk uses real carton sizes, freight and the exact tariff line.
- FOB goods (100)
- $10,500
- Ocean freight + handling (2.6 CBM, volume guessed from price)
- $1,015
- US duty (3.5%)
- $368
- Section 301 tariff (25.0%)
- $2,625
- Customs fees (MPF/HMF)
- $49
Estimate in USD to a US port using category averages, rates as of 2026-09. Other countries on request. A quote from our desk uses real carton sizes, freight and the exact tariff line.
Verify from $29 · written report in 3 business days · 100% refund if not satisfied
TUF-2000B DN50-DN700 External Clamp Type Plug-in Wall-mounted Ultrasonic Flowmeter
Dalian Teren Instruments Co.,LtdSee what’s includedHide breakdown
- FOB goods (100)
- $10,500
- Ocean freight + handling (2.6 CBM, volume guessed from price)
- $1,015
- US duty (3.5%)
- $368
- Section 301 tariff (25.0%)
- $2,625
- Customs fees (MPF/HMF)
- $49
Estimate in USD to a US port using category averages, rates as of 2026-09. Other countries on request. A quote from our desk uses real carton sizes, freight and the exact tariff line.
- FOB goods (100)
- $10,500
- Ocean freight + handling (2.6 CBM, volume guessed from price)
- $1,015
- US duty (3.5%)
- $368
- Section 301 tariff (25.0%)
- $2,625
- Customs fees (MPF/HMF)
- $49
Estimate in USD to a US port using category averages, rates as of 2026-09. Other countries on request. A quote from our desk uses real carton sizes, freight and the exact tariff line.
Verify from $29 · written report in 3 business days · 100% refund if not satisfied
About this product
- Size: 41*27*17cm
- Color: Blue
- Exports to: Africa, Middle East, Southeast Asia, South Asia, Central Asia, USA and Canada, Latin America, Russia, EU, Other European Countries, Japan and South Korea, Hong Kong China, Macao China and Taiwan China
About this product
- Size: 41*27*17cm
- Color: Blue
- Exports to: Africa, Middle East, Southeast Asia, South Asia, Central Asia, USA and Canada, Latin America, Russia, EU, Other European Countries, Japan and South Korea, Hong Kong China, Macao China and Taiwan China
Product details
| Size | 41*27*17cm |
|---|---|
| Color | Blue |
Product details
| Size | 41*27*17cm |
|---|---|
| Color | Blue |
From the supplier
Items
Performance &Parameter
Convertor
Principle
Transit-time ultrasonic flowmeter
Accuracy
±1%
Display
2x20 character LCD with backlight, support the language of Chinese, English, Italy, Turkish
Signal output
1way 4-20mA output, electric resistance 0-1K, accuracy0.1%
1 way OCT pulse output(Pulse width-1000ms, default is 200ms))
1 way Relay output
Signal input
3 way 4-20mA input, accuracy 0.1%, acquisition signal such as temperature, press and liquid level
Connect the temperature transducer P100, can finish the heat/energy measurement.
Data Interface
Insulate Rs485 serial interface, upgrade the flowmeter software by computer, support the MODBUS.
Special Cable
Twisted-pair cable, generally, the length under 50 meters, select the Rs485, transmission distance can over 1000m
Pipe Installation Condition
Pipe material
Steel, stainless steel, cast iron, copper, cement pipe, PVC, Aluminum, glass steel product, liner is allowed
Pipe diameter
25-6000mm
Straight pipe
Transducer installation should be satisfied: upstream10D, downstream5D, 30D from the pump.
Measuring Medium
Type of liquid
Single liquid can transmit sound wave; such as water (hot water ,chilled water, city water, sea water, waste water, etc); sewage with small particle con tent, oil(curde oil, lubricating oil, diesel oil, fuel oil, etc); chemicals(alcohol, etc); plant effluent; beverage; Ultra-pure liquids, etc
Temperature
-30-160℃
Turbidity
No more than 10000ppm and less bubble
Flow rate
0-±7m/s
Temperature
Convertor; -20-60℃; Flow Transducer: -30-160℃
Humidity
Convertor: 855RH; Flow Transducer: can measure under water, water depth≤2m
Working Environment
Temperature
Convertor; -20-60℃; Flow Transducer: -30-160℃
Humidity
Convertor: 855RH; Flow Transducer: can measure under water, water depth≤2m
Power Supply
DC8-36V or AC85-264V(Optional)
Power Consumption
1.5W
Dimension
132*150*85mm(convertor)
From the supplier
Items
Performance &Parameter
Convertor
Principle
Transit-time ultrasonic flowmeter
Accuracy
±1%
Display
2x20 character LCD with backlight, support the language of Chinese, English, Italy, Turkish
Signal output
1way 4-20mA output, electric resistance 0-1K, accuracy0.1%
1 way OCT pulse output(Pulse width-1000ms, default is 200ms))
1 way Relay output
Signal input
3 way 4-20mA input, accuracy 0.1%, acquisition signal such as temperature, press and liquid level
Connect the temperature transducer P100, can finish the heat/energy measurement.
Data Interface
Insulate Rs485 serial interface, upgrade the flowmeter software by computer, support the MODBUS.
Special Cable
Twisted-pair cable, generally, the length under 50 meters, select the Rs485, transmission distance can over 1000m
Pipe Installation Condition
Pipe material
Steel, stainless steel, cast iron, copper, cement pipe, PVC, Aluminum, glass steel product, liner is allowed
Pipe diameter
25-6000mm
Straight pipe
Transducer installation should be satisfied: upstream10D, downstream5D, 30D from the pump.
Measuring Medium
Type of liquid
Single liquid can transmit sound wave; such as water (hot water ,chilled water, city water, sea water, waste water, etc); sewage with small particle con tent, oil(curde oil, lubricating oil, diesel oil, fuel oil, etc); chemicals(alcohol, etc); plant effluent; beverage; Ultra-pure liquids, etc
Temperature
-30-160℃
Turbidity
No more than 10000ppm and less bubble
Flow rate
0-±7m/s
Temperature
Convertor; -20-60℃; Flow Transducer: -30-160℃
Humidity
Convertor: 855RH; Flow Transducer: can measure under water, water depth≤2m
Working Environment
Temperature
Convertor; -20-60℃; Flow Transducer: -30-160℃
Humidity
Convertor: 855RH; Flow Transducer: can measure under water, water depth≤2m
Power Supply
DC8-36V or AC85-264V(Optional)
Power Consumption
1.5W
Dimension
132*150*85mm(convertor)
