Pipe Threading Machine 4” P100F

Fast & Powerful!



1100W induction motor, 2-speed 30 rpm and 14 rpm no load.

Reinforced gearbox, 20CrMn Ti, 40Cr material with special heat treatment, provides improved machine service life and precision.

Heavy-duty proven performance on threading and cutting.

Self-centering Cutter.

5 flute cone reamer, high efficiency debur on tube.

Easily replaceable clamping jaws.

New epoxy powder coating.

G.W./N.W.: 145/125Kg

MEAS: 96×65×61cm

Standard Equipment:

Supplied with 1 Profiling Die Head 1/2”-2” and 1 Profiling 2.1/2”-4” Die Head, right Dies sets (1/2”-3/4”), (1”-2”) and (2.1/2”-4”), 4 legs, 1 cutting oil, 1 cutting oil canister and one set of mounting tools.



Code

Voltage

Power

Dies Type

Remarks

94F20

220V 50/60Hz

1100W

BSPT



94F25

220V 50/60Hz

1100W

NPT



94F10

110V 50/60Hz

1100W

BSPT



94F15

110V 50/60Hz

1100W

NPT





"}
